WARNING
This product has been designed for seating three (3) average adults. To prevent injury and damage to this unit, PROHIBIT jumping on it.
This product is designed for home use and not intended for commercial use.
Children under the age of 5, small infants and babies should not sleep alone on this product for safety reasons.
Recommended # of people needed for handling: 2 (however it is always better to have an extra hand.)
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WW - 11 / 29 / 2018
SOFA
ASSEMBLY INSTRUCTIONS
Advertisement
Related Manuals for Lifestyle Solutions Hamburg Mid Century Modern
Summary of Contents for Lifestyle Solutions Hamburg Mid Century Modern
- Page 1 SOFA ASSEMBLY INSTRUCTIONS WARNING This product has been designed for seating three (3) average adults. To prevent injury and damage to this unit, PROHIBIT jumping on it. This product is designed for home use and not intended for commercial use. Children under the age of 5, small infants and babies should not sleep alone on this product for safety reasons.
- Page 2 PARTS Sofa Body Backrest QTY:1 QTY:1 ( In the storage underneath of sofa body) M10 Washer QTY:1 Pair QTY:4 (Outer Dim. 45mm) ( In the storage underneath of sofa body) QTY:4...
- Page 3 Step 1 : Carefully unpack parts/hardware from box and storage of seat body, place on a clean flat surface. HARDWARE Storage, underneath of sofa body.
- Page 4 Step 1 : Place both arms as shown below, secure two legs and plastic washers into pre-drilled holes on the bottom of arms. Please avoid overtightening. × 4 × 4...
- Page 5 Step 2 : Carefully lift and turn assembled arms onto its legs.Insert seat body metal plates to both arms as shown below. Ensure it is correctly in place.
- Page 6 Step 4 : Insert backrest metal plates to both arms as shown below.Ensuring it is correctly in place. Metal plate on backrest Metal plate on Armrest...
- Page 7 Step 4: Finally, stretch and pull down rear cover evenly before securing velcro strip to seat base. Repeat if necessary for better fit.
-
Page 8: Installation Complete
INSTALLATION COMPLETE : Need assistance? Please call : 866-626-7826 For prompt, reliable service; please have your assembly manual ready.
