Lifestyle Solutions HARRINGTON Assembly Instructions

Place the left armrest as shown below, insert the metal plates on the

armrest to the one on the chaise body.

Ensure it is correctly in place.

Metal plate

on armrest

Metal plate

on chaise

If you want to place loveseat on left side and chaise on right side,

please follow the leg positions as shown below when assembling the

item.

8 of 8

Optional leg for

added support

Optional leg for

added support

Rev.10282016

HARRINGTON

TOLL FREE 877-693-8866 LIFESTYLE SOLUTIONS

Table of Contents

Need help?

Do you have a question about the HARRINGTON and is the answer not in the manual?

Page 1 Optional leg for added support If you want to place loveseat on left side and chaise on right side, please follow the leg positions as shown below when assembling the item. HARRINGTON 8 of 8 Rev.10282016 TOLL FREE 877-693-8866 LIFESTYLE SOLUTIONS...
Page 2 PARTS AND HARDWARE Secure the back cushion by locating the open-ended zipper pin/box. Fasten Avoid using sharp objects such as a knife to open packing as you may accidentally damage the upholstery. both sides and continue all the way to the end. Flip the back cushion into the position when finished.
Page 3 ASSEMBLY INSTRUCTIONS Place the chaise body and chaise backrest as shown below, secure legs and plastic washers into the pre-drilled holes on the bottom of each CAUTION: At least two adults are required to safely complete performing this task. part as shown. Please avoid overtightening. Other lifting attempts may risk back injury due to large and heavy part(s).
Page 4 Carefully lift and turn assembled parts onto its legs. Unzip all the back cushion covers, insert the back cushions to the correct back cushion Insert loveseat body metal plates to loveseat backrest as shown below. covers, make sure the back cushions are flat in the covers. Ensure it is correctly in place.
