Tektronix 1502C Service Manual page 191

Replaceable Electrical Parts
Replaceable Parts List (Cont.)
Assy Tektronix Serial No.
Number Part Number Effective
A3A1R2014 322–3357–00
A3A1R2015 322–3289–00
A3A1R2016 322–3097–00
A3A1R2017 322–3385–00
A3A1R2018 322–3385–00
A3A1R2020 321–0253–00
A3A1R2021 322–3222–00
A3A1R2022 322–3193–00
A3A1R2023 322–3261–00
A3A1R2024 322–3239–00
A3A1R2025 322–3239–00
A3A1R2026 322–3289–00
A3A1R2027 308–0839–00
A3A1R2030 322–3326–00
A3A1R2031 317–0027–00
A3A1R2032 308–0767–00
A3A1S2010 260–2370–00
A3A1T1030 120–1608–00
A3A1T1031 120–0487–00
A3A1TP1010 214–0579–02 B020000
A3A1TP1020 214–0579–02 B020000
A3A1TP2010 214–0579–02 B020000
A3A1TP2030 214–0579–02 B020000
A3A1U1010 156–0933–00
A3A1U1011 156–1173–00
A3A1 670–9286–XX
A3A1U1020 156–1225–00
A3A1U1021 156–1225–00
A3A1U1022 156–1173–00
A3A1U1023 156–0933–00
8–24
