DK2 Power OPC503 Assembly Manual

Chipper shredder top loading
Hide thumbs Also See for OPC503:

Advertisement

Quick Links

Download this manual
CHIPPER ASSEMBLY GUIDE
MODEL: OPC503
3 INCH CHIPPER SHREDDER TOP LOAD
DETAIL K2 INC.
DK2 POWER USA
DETAIL K2, INC.
DK2 USA EAST
4301 S Valley View Blvd STE 10-11
1080 Clay Avenue Unit 2
6245 Industrial Parkway
Las Vegas, NV 89103
Burlington, Ontario, Canada L7L0A1
Whitehouse, OH 43571
1-702-331-5353
PARTS AND SERVICE 702-331-5353 OR
WWW.DK2POWER.COM
CONTACT US
CHIPPER SHREDDER TOP LOADING
OFF ROAD TOWING ONLY
REV 4 9-7-2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the OPC503 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DK2 Power OPC503

Summary of Contents for DK2 Power OPC503

  • Page 1 CHIPPER ASSEMBLY GUIDE MODEL: OPC503 3 INCH CHIPPER SHREDDER TOP LOAD DETAIL K2 INC. DK2 POWER USA DETAIL K2, INC. DK2 USA EAST 4301 S Valley View Blvd STE 10-11 1080 Clay Avenue Unit 2 6245 Industrial Parkway Las Vegas, NV 89103...
  • Page 2 STEP 1: 1. Install the axle with bolts provided.
  • Page 3 STEP 2 1. Install wheels. Use locking pins in axle to lock wheels from moving while your chipping, or free wheel when towing.
  • Page 4 STEP 3: 1. Install drop stand 2. Install Tow Bar...
  • Page 5 STEP 4: 1. Install the 3 inch tree feed chute with the bolts provided.
  • Page 6 STEP 5: 1. Install handle with 4 bolts.
  • Page 7 STEP 6: 1. Mount the top chute to the unit. 2. Plug in the white connector for the key switch...
  • Page 8 STEP 7: 1. Mount the chip chute...
  • Page 9 STEP 8: 1. Fill oil 10w30 2. Gas mid grade 3. Small sticks 3/8 dia max and leaves in top hopper 4. Trees up to 3 inches into side feed chute...
  • Page 10 STEP 9: READ THE ENGINE MANUAL SUPPLIED WITH YOUR UNIT FOR FULL ENGINE OPERATION, SAFETY, AND MAINTENANCE. ON/OFF KEY LOCK GAS – USE MID GRADE OR HIGHER CHOKE – LEFT IS ON / RIGHT IS OFF (RUN POSITION) GAS ON/OFF SWITCH – LEFT IS OFF / RIGHT IS ON THROTTLE –...
  • Page 12 Ref.No. Description Ref.No. Description hitch trailer middle chipper room Bolt M10*50 outside chipper room washer 10 M8*20 Bolt lock nut M10 cover plate Tow bar M6*20 bolt safety pin Φ8*60 M6*25 bolt tow bar connecting part washer 6 Hexagon flange boltM8*55 spring washer 6 rubber washer M30*15 lock nut M6...
  • Page 13 OPERATION – BEFORE TURNING KEY AND PULL STARTING ENGINE CLEAR AREA OF ALL PEOPLE AND PROPERTY THAT COULD BE DAMAGED. THINK SAFETY. CHIPS ARE FLYING PROJECTILES AND CAN CAUSE INJURY. WEAR SAFETY GLASSES, HEARING PROTECTION, AND GLOVES DO NOT WEAR LOOSE FITTING CLOTHES THAT COULD GET STUCK IN THE MACHINE MOVING PARTS, ONLY CHIP WOOD, CHILDREN SHOULD NOT RUN THIS EQUIPMENT, STAY ALERT OF YOUR SURROUNDING AND PERSONS THAT COULD APEAR IN THE CHIP PATH WHILE YOU ARE WORKING.

  • Page 14: Quick Start Setup

    QUICK START AND TROUBLE SHOOTING GUIDE QUICK START SETUP • ADD 10W30 OIL TO ENGINE • ADD GAS • PIN BOTH WHEELS INTO PIVOT BRAKE HOLES. • TURN KEY ON • HALF THROTTLE (CHOKE OPTIONAL FOR COLD STARTS) • SET THROTTLE TO JUST OVER TURTLE •...
  • Page 15 (1) year from the date of the original purchase. If within one (1) year from the original date of purchase this OPC503 fails due to defect in material or workmanship, Detail K2 will repair, replace, or supply any covered defective part at our option.
