ITEM DESCRIPTION
1 STRAIN RELIEF
2 10-32 X 1/4 SET SCREW
3 MOTOR HOUSING
4 GEAR MOTOR WITH ENCODER
5 SOCKET HEAD CAP SCREW
6 O-RING 225
7 ACTUATOR LOWER HOUSING
8 SHCS W/ SILICONE HEAD SEAL
9 DRIVE SHAFT
10 QUAD-RING-207
11 FLANGED SLEEVE BEARING
12 6-40 X 1/4 SOCKET SET SCREW CUP POINT
13 TIMING PULLEY
14 FLANGED SLEEVE BEARING
15 COUPLING 1.5"NH ROCKERLUG
16 GASKET
17 PORT PLUG
18 TIMING BELT
19 DOWEL PIN
20 ROLLER
21 ACTUATOR UPPER HOUSING
22 TASK FORCE TIPS LOGO LABEL
23 DUST COVER
24 3/16" BALL - STAINLESS STEEL
25 BASE
27 O-RING-125
HEAD 20/60 GPM
28
HEAD 20/95 GPM
29 QUAD-RING-225
30 SEAT
31 BAFFLE
32 3/8 X 5/16 SHOULDER SCREW
33 DETENT SCREW
34 SPRUNG HELICAL COMPRESSION
35 3/16" BALL - TORLON
36 1.5" BUBBLE CUP SLEEVE
37 1.5" BUBBLE CUP CAP W/ TEETH
38 LABEL: BUBBLE CUP 20 & 60/95
39 CABLE - 6 POLE MALE IN-LINE PLUG
40 O-RING112
41 SPRING WASHER
QTY PART #
1 Y6010
1 VT10Y32SS250
1 F768
1 Y6001
6 VT25-28SH1.7
1 VO-225
1 F766
4 VTM4S0.7SH8
1 F765
1 VOQ-4207
1 F773
2 VT06-40SS250
1 F770
1 F772
1 F10097N
2 V3130
1 B770
1 F771
2 VP250X1.50
2 F769
1 F767
1 HE195
1 F774
34 V2120
1 F760
1 VO-125
1 F761
1 F762
1 VOQ-4225
1 F650
1 F631
1 F635
2 D290
2 VM4195
2 V2120-TORLON
1 F660
1 F685
1 FL83
1 Y5480
1 VO-112
1 F636
