16. MPC2000D Installation
16.1 Casing
The MPC2000D is supplied in a UK manufactured industry standard drawout case for flush mounting on the front of
the motor starter or circuit breaker cubicles.
102
96
45
208
Page 38
96
45
10
PUSH BUTTON
PROJECTION 10mm
178.5
178
Required to open case
Issue 2 22/4/98
156
168
202
Min
28
166.25
40
M4 STUDS
23
4 HOLES 4.3mm DIAMETER
158
PANEL CUT OUT FLUSH
MOUNTING FIXING DETAILS
NOTE Minimum gap between vertical
spacing is required in order to
withdraw relay from the case above.
Clearance
25 min
155.5
NOT SHOWN TO SCALE
MPC2000D
