Summary of Contents for Wickes CDT212W.4
- Page 1 CORDLESS DRILL DRIVER 10.8V LITHIUM CDT212W.4 223729...
-
Page 2: Table Of Contents
CONTENTS GENERAL POWER TOOL SAFETY WARNINGS GENERAL SAFETY WARNINGS FOR BATTERY CHARGER COMPONENT LIST ACCESSORIES SYMBOLS TECHNICAL DATA NOISE INFORMATION OPERATING INSTRUCTIONS TROUBLESHOOTING MAINTENANCE ENVIRONMENTAL PROTECTION DECLARATION OF CONFORMITY... -
Page 3: General Power Tool Safety Warnings
ORIGINAL INSTRUCTION GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings, 3. PERSONAL SAFETY a) Stay alert, watch what you are doing and use instructions, illustrations and specifications provided with this power tool. Failure to follow all common sense when operating a power tool. Do instructions listed below may result in electric shock, fire and/ not use a power tool while you are tired or under the influence of drugs, alcohol or medication. - Page 4 GENERAL POWER TOOL SAFETY WARNINGS the power tool before making any adjustments, c) When battery pack is not in use, keep it away from changing accessories, or storing power tools. Such other metal objects, like paper clips, coins, keys, preventive safety measures reduce the risk of starting the nails, screws or other small metal objects, that can power tool accidentally.
- Page 5 the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury. c) Apply pressure only in direct line with the bit and do not apply excessive pressure. Bits can bend causing breakage or loss of control, resulting in personal injury. SAFETY WARNINGS FOR BATTERY PACK a) Do not dismantle, open or shred cells or battery pack.
-
Page 6: General Safety Warnings For Battery Charger
GENERAL SAFETY WARNINGS FOR BATTERY CHARGER WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 7: Component List
COMPONENT LIST Keyless chuck Battery pack release button Torque adjustment ring Battery pack Two-speed gear control On/off switch Forward/Reverse rotation control LED light Soft grip handle Charger ACCESSORIES 1 hr charger (ACG112W1) 1.5Ah Li-ion battery pack (ABP1215HW) Magnetic bit holder We recommend that you purchase your accessories from the same store that sold you the tool. -
Page 8: Symbols
SYMBOLS Li-ion battery. This product has been marked To reduce the risk of injury, read all of this with a symbol relating to ‘separate collection’ instruction manual for all battery packs and battery pack. It Li-Ion will then be recycled or dismantled in order Warning to reduce the impact on the environment. -
Page 9: Technical Data
TECHNICAL DATA Voltage 10.8V No load speed 0-350/0-1350/min Number of clutch positions 18+1 Max torque 25N.m Chuck capacity 10mm Charger Protection class Charging time Charger Input 100-240V~50/60Hz, 25W Charger Output 12VDC 1.5A Max. drilling capacity Steel 10mm Wood 25mm Machine weight (With battery pack) 1 Kg Battery capacity 1.5Ah Li-ion battery... - Page 10 VIBRATION INFORMATION Vibration total values (triax vector sum) determined according to EN 62841: Vibration emission value a = 2.37m/s² Drilling into metal Uncertainty K = 1.5 m/s² The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use The machine is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic. BEFORE PUTTING INTO OPERATION A) CHARGING THE BATTERY The battery supplied is partially charged. - Page 12 D) HOW TO CHARGE YOUR BATTERY PACK (See Fig. A3) CHARGING PROCEDURE 1) Plug the charger into an appropriate outlet, the green LED will light. 2) Slide the battery pack into the charger, the red LED will light to indicate that charging has started. 3) When charging has completed, the green LED will light.
- Page 13 3. REVERSIBLE (See Fig. C1, C2) Forward rotating: push the forward/reverse rotation control (4) to the left (the drill points away from you). It is used for drilling and screw driving. Reverse rotation: push the forward/reverse rotation control (4) to the right (the drill points away from you). It is used for remove screws or release a jammed drill bit.
- Page 14 6. TORQUE ADJUSTMENT (See Fig. F) (Screw driving force of your drill driver) The torque is adjusted by rotating the torque adjustment ring (2). The torque is greater when the torque adjustment ring (2) is set on a higher setting. The torque is less when the torque adjustment ring (2) is set on a lower setting.
-
Page 15: Troubleshooting
10. OVERLOAD PROTECTION When overloaded, the motor comes to a stop. Relieve the load on the machine immediately and allow cooling for approx. 30 seconds at the highest no-load speed. 11. TEMPERATURE DEPENDENT OVERLOAD PROTECTION This power tool has over-load protection built in. If the load is too high or the battery temperature exceeds 75°C, the electronic control switches off the power tool until the battery has cooled. -
Page 16: Maintenance
MAINTENANCE Your tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of dust. -
Page 17: Declaration Of Conformity
DECLARATION OF CONFORMITY Wickes Building Supplies Limited Declare that this product: CORDLESS DRILL DRIVER Description and SKU code: 223729 Complies with the following Directives and Regulations: 2006/42/EC, Machinery Directive 2014/30/EU, Electromagnetic Compatibility Directive 2011/65/EU & (EU)2015/863 (RoHS),Restriction of Hazardous Substances Directive... - Page 20 Customer Helpline 0345 2005409...
