AudioArts Engineering R-55 Technical Manual page 62

ITEM#
R10, R13, R32, R35, R78
R39, R40, R42, R43, R45, R47, R49, R50, R108
R51
CR1-CR6
CUE POT
CR7-CR10
SW1-SW4
CUE KNOB
CUE CAP
EXT/PGM/AUD/MONO SWITCH BUTTON
K1, K2
DS1
DS2, DS4
DS3
DS5
PCB_BPSA1000
PCB_OM2000
F1-F3
R-55 / Mar 2003
OM-55 OUTPUT MODULE PARTS LIST
10.0 KOHM 1% .25W MC1206 RESISTOR
40.2 KOHM 1% .25W MC1206 RESISTOR
88.7 KOHM 1% .25W MC1206 RESISTOR
10K TRIM POT
10KΩ SINGLE AUDIO CONDUCTIVE PLASTIC, BOURNS
10K TRIM POT SMT
2 POLE PUSHBUTTON SWITCH, MOMENTARY
1/8" COLLET KNOB, NO POINTER, NO LINE
PASTEL GREEN CAP W.BLACK LINE FOR 15MM KNOB
CUSTOM WHITE LIGHT PIPE BUTTON
DPDT RELAY,5V
HIGH INTENSITY AMBER SMT LED RIGHT ANGLE
ULTRABRIGHT RIGHT ANGLE RED SMT LED
ULTRABRIGHT RIGHT ANGLE GREEN SMT LED
ULTRABRIGHT RIGHT ANGLE YELLOW SMT LED
PRINTED CIRCUIT BOARD
PRINTED CIRCUIT BOARD SMT
D SUB STANDOFFJACK HARDWARE 3/16" LONG
PEM FASTENERS
FUSE/ POLYSWITCH .3AMP SMT RESETABLE
DESCRIPTION QTY W#
5 435028
9 435039
1 435043
6 500021
1 500058
4 505002
4 510113
1 520053
1 530079
4 530083
2 550006
1 605010
2 605017
1 605018
1 605019
1 700299
1 700655
4 820047
4 821009
3 835001
page 10 - 5
