Line Preselector Module

Module Overview

This optional module electronically selects one of six stereo line
sources and routes it to one stereo output, allowing you to expand the
source capability of an input channel or monitor module.
All audio input and output signals are made via two DB-25 multi-pin
connectors mounted at the top of the module and located underneath the
hinged meterbridge.

Internal Programming Options

There are no internal programming options on the LS-55 module.
R-55 / Mar 2003
L I N E P R E S E L E C T O R M O D U L E
(LS-55; optional)
