1.3 Hardware resources list

CoLinkEx_LPC11C14 EVB Kit contains CoLinkEx and LPC11C14 board:
On board CoLinkEx
A mini-type USB socket, power supply
and communicate with PC
2mm*10pin Debug Interface, can debug
other devices
a power supply LED
3 CoLinkEx Status LED: D1~D3
The suite contains the CoLinkEx_LPC11C14 EVB Kit and the following issues:
MiniUSB Line
2mm*10pin to DB9 serial line
Two 2.54mm Jumper cap
A CD and Publicity Color Pages

1.4 Software resources list

Example Name
Default factory program
Blinky
UART_Print
Master_Transfer
WDT_Reset
LPC11C14_Dev_Board
CAN Interface
An Serial connection socket ( support RS-485
/ EIA-485)
1 LED(P2.9)
Full function IO extension , support I2C, SPI,
ADC
Function Description
LED4 Blink, UART Send data, I2C Read Temperature
sensor
LED4 Blink
UART Send data
Read data though I2C (Need to connect EEPROM)
Watchdog application example.
