4. CoLinkEx Installation and Use

4.1

Installation

To install CoLinkEx, you need to do the following:

Update the firmware

Install the Driver of CoLinkEx
Connect CoLinkEx to PC
4.1.1 Update the firmware
If you are using CoMDKPlugin V1.4.0, CoIDE V1.4.0, or CoFlash V1.4.0, you need to update
CoLinkEx driver and firmware before using CooCox CoLinkEx.
The firmware can be found in the disk: Tools\ColinkEx_Driver\ColinkEx_firmware_v0.4.bin
How to update the firmware:
1）Short-circuit JP1.
2）Connect CoLinkEx to the PC.
Wait for the PC enumerates the removable disk whose label is "CRP2 ENABLD" or "CRP
DISABLD". If it does not, you could press the reset button (BP1) for several times or power
on again.
Delete the firmware.bin file in removable disk.
3）Copy the downloaded firmware: ColinkEx_firmware_v0.4.bin into the removable disk.
4）Disconnect JP1, power on again, then CoLinkEx will work normally.
