2.3 SW/JTAG Debug Interface

CoLinkEx_LPC11C14 EVB Kit use ARM standard 2mm*10 pin SW/JTAG Interface.
You can use this interface to debug other devices. See:
other devices. You can also use other adapter to debug the LPC11C14board, such as
ULink2, J-Link.

2.4 UART

The Universal Asynchronous Receiver Transmitter features a 9-pin UART that can be
used for communication and trace purposes. It offers an ideal channel for ISP
downloading. Use the following line to connect the board and PC.

2.5 CAN

CAN Interface, use TJA1040 Controller, can connect through J9. It offers an ideal
channel for ISP downloading, too.

2.6 Mini USB Port

A Mini USB AB interface supplies 5V voltage to the Board. CoLinkEx communicate
with the PC through this port.
How to use CoLinkEx to debug
10
