1.2.

Checking the compatibility of vehicle and accessories

Brand Compatible vehicles
C-Max since model year 2018
Ecosport since model year 2017
Fiesta model year 2018 since 07/2017
Focus since model year 2017
Galaxy since model year 2016
Kuga model year 2018
Mondeo since about 2017
Mustang since model year 2017
Ford
Puma
Ranger since model year 2017
S-Max since model year 2016
Tourneo Connect
Tourneo Custom
Transit since model year 2017
Transit Custom since facelift 2018
and other vehicles with
Limitations
Video only
Factory rear-view camera
After market front camera
Guidelines and PDC
Version 09.12.2020
Compatibility
The interface inserts ONLY video signals into the infotainment.
For inserting Audio signals either the possibly existing factory
audio-AUX-input or a FM-modulator can be used.
In case that 2 AV sources shall be connected, a desired audio
switching will require additional electronic.
Automatically switching-back from inserted video to factory rear-
view camera is only possible while the reverse gear is engaged. To
delay the switch-back an additional electronic part is required.
The front camera will automatically be switched for 10 seconds
after disengaging the reverse gear. A manually front camera
switching is possible by external keypad.
Displayed guidelines and PDC are not available in all vehicles.
HW: CAM(V100)/(V11+V41)
Infotainment systems
Sync3 Light (R5) version with 6.5inch,
7inch or 8inch tablet monitor
Sync Connected Radio version
with 4inch monitor
Sync3 full version with APIM and with
7inch or 8inch tablet or non-table
monitor – Non Plug & Play installation.
For Plug & Play the RL4-SY3 is available)
Only up to Sync3 with firmware 3.3
ab Serien Nr: NZ20NOV694 RL4-SY3-R5
