ZKTeco 8000 Series Quick Start Manual

Hide thumbs Also See for 8000 Series:

Advertisement

Quick Links

Download this manual
Quick Start Guide
8000 Series Network Video Recorder
Version: 1.0
Date: October 2018

Advertisement

loading

Related Manuals for ZKTeco 8000 Series

Summary of Contents for ZKTeco 8000 Series

  • Page 1 Quick Start Guide 8000 Series Network Video Recorder Version: 1.0 Date: October 2018...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS These instructions are intended to ensure that users use the device correctly to avoid danger or property damage. Relevant precaution measures are divided into ”Warning” and ”Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

  • Page 3: Installation Of The Hard Disk

    INSTALLATION OF THE HARD DISK Disconnect the power from the NVR before you open the case to install or replace a hard disk drive (HDD). It is recommended to use officially authorized HDD for device installation. Step 1: Loosen the screws of the Step 2: Fix four screws in the HDD.

  • Page 4: Front Panel Setup

    Step 5: Fix the HDD. Step 6: Connect the power cable and SATA cable. Then install the cover again. FRONT PANEL SETUP Indicator Name Function Network Status NET LED is normally green, indicating that Indicator the network connection is normal. PWR LED is normally green, indicating that Power Status Indicator the device is functioning properly.
  • Page 5 LOCALSYSTEM LOGIN STARTING UP: Proper starting up and shut down procedures are crucial to expanding the life of the NVR. Please make sure the power adapter is compatible with the NVR and make sure the NVR is connected to ground. Before starting up, please make sure the NVR is connected to ground.
  • Page 6 Step 2: Access of the login interface Click on the “Start” icon, click on “Login”, then enter the username and password to login in. The default user name is “admin”; and the default password is “123456”. After logged in to the system, click on “Start”  ”Menu”, then the main menu will pop up. Main Menu...
  • Page 7 Step3: Channel settings Click on “Start”  ”Menu”  ”Channel Manage” to set channel. Channel Setting...
  • Page 8 Step 4: Device searching Click “Add channel”  ”Refresh” to search for the desired IP camera. Device Searching...
  • Page 9 Step 5: Device adding Click on “Stop”, choose the checkboxes for the cameras you want to add and click on the “OK” button, then the system will add the cameras automatically. Device Adding...
  • Page 10 Step 6: Checking connection status Port (port of the ONVIF protocol is “80” and that of the private protocol is subject to the rules of the specific protocol). icon Protocol (if connection is abnormal under ONVIF, click on the “Edit” , enter the username and password and save the changes).
  • Page 11 Step 7: Record settings Click on “Start”  ”Menu”  ”Record Manage” to set the recording plan. Configure recordings: a) select a recording channel; b) select a record mode and recording period; c) click on “Save” (if the other channels require the same configuration, click on “Copy to”...
  • Page 12 Step 8: Record playback Click on “Start”  ”Menu”  ”Playback” to enter the playback interface. Playback of videos Choose a playback mode from area 1 as shown in the picture below. Choose a playback channel from area 2 as shown in the picture below. Choose the record time and filter.

  • Page 13: Remote Control

    REMOTE CONTROL Mobile Application Access 1. Click on “Start”  ”Menu”  ”Network Manage”  ”Platform Settings”  ”AntarView Pro”, scan the QR code for APP to download and install the application from Apple store or Google Play. NVR-end Setting for APP...
  • Page 14 2. After installation, tap the icon to enter “Real-time Preview”, as shown in the figure below. Real-time Preview...
  • Page 15 3. Add IPC: Swipe right to access the main menu and tap “Device Manage”, then tap the “+” button to add a new device. Main Menu Add Device...
  • Page 16 4. Input the NVR serial number or scan the NVR’s QR code, input the device’s name, username and password, then tap “Save” to complete the configuration. NVR Information...
  • Page 17 PC Application Access 1. Install CMS application on your computer. 2. Click on “Device Management” to search, add, delete, modify network devices. Input the device’s name, port, IP address, account and password to manually add the devices. CMS Device Management...
