Quick Start Guide
8000 Series Digital Video Recorder
Version: 3.0
Date: October 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZKTeco 8000 Series

Summary of Contents for ZKTeco 8000 Series

  • Page 1 Quick Start Guide 8000 Series Digital Video Recorder Version: 3.0 Date: October 2018...
  • Page 2 Thank you for purchasing our device! Declaration The user’s manual is designed to be a reference tool for your system. As our products are regularly updated, we cannot guarantee exact consistency between the actual product and the written information in the manual. Screenshots shown are for illustration purpose only.
  • Page 3 4. Qualified engineers needed All examination and repair should be carried out by qualified service engineers. We assume no responsibility for any damages caused by unauthorized modification or repair. 5. Environment The DVR should be installed in a cool and dry place away from direct sunlight and inflammable or explosive substances.

  • Page 4: Unpacking Inspection

    1 Installation 1.1 Unpacking Inspection When you receive the device, please check if all items are in the box according to the packing list in the box. 1.2 HDD Installation Tools: A cross screwdriver. ① Remove the ② Install the HDD ③...
  • Page 5 USB2.0 interface: 1. Connecting the mouse; USB Port 2. Connecting the USB with the device to back up videos or upgrade the firmware. Menu Menu Access the menu interface. Start recording. 1. Assisting functions such as PTZ menu; 2. During monitoring, press the keys to switch between multiple-window and one-window;...
  • Page 6 HDD Light When it is lit, there is no HDD or HDD error. When the device is connected to the network cable, Network the light is on; when there is IP conflict, the light will Light flash. Rec Light It is lit during recording. Receive remote control signals.

  • Page 7: Alarm Input Connection

    1. Connecting the mouse; USB interface 2. Connecting the USB with the device to back up videos or upgrade the firmware. Power input DC 12V/2A, DC 12V/3.3A, DC 12V/4A, AC220V. 1.5 Alarm Connection Name Descriptions Name Descriptions RS485 interface NO1.C Alarm out NO2.C Alarm out...

  • Page 8: Power Off

    3. Choose the correct PTZ protocol in menu [Config]  [Channel]  [P/T/Z]. Note: 120Ω resistors should be connected in parallel with remote A/B lines to reduce the signal distortion if a larger number of PTZs are connected. 2 Basic Operation Guide 2.1 Power On Install the DVR correctly (as above) and connect it to the power.
  • Page 9 2.4 Preview After login the system, it is in live mode. You can find the date and time of the system, the channel’s name, and so on. The Preview GUI There is a “Start” button on the bottom-left corner. Click on it to choose from accessing the main menu and other options.

  • Page 10: Channel Management

    2.5 Channel Management 2.5.1 Mode Switch Click on [Start]  [System Manage]  [System Parameters]  [Display Parameters]  [Display Mode] to set the channel’s parameters. There are multiple options for full-analog mode and composite mode. 2.5.2 IP Channel If you use composite mode, you can manage the IP channels and Analog channels at [Start] ...
  • Page 11 Manual Add: Click on [Add Channel]  [Manual Add], then fill in the correct parameters to add the IPCs. Auto Add: Click on [Add Channel] and select [Auto Add], click on [Search] to search and select the available IP cameras, and click on [Add] to add. Note: Features mentioned in this section are only available to devices which support IP channels.

  • Page 12: Ptz Control

    2.6 PTZ Control Follow the below steps to control PTZ. 1. Go to the preview interface, left-click on the PTZ channel, then the menu will pop up; click on the PTZ icon to entry the PTZ control interface. 2. Configure the parameters. [Speed] The speed ranges from 1 to 16.
  • Page 13 2.7 Playback Click on [Start]  [Playback]  [Search] to start playback operations. Note: The HDD must be R/W HDD or Read HDD. Files available for playback are kept in HDDs. Index Type Descriptions Playback Mode Regular Playback/ Image Playback/ USB Playback. Select Channels Choose the channels for querying.

  • Page 14: Network Settings

    2.8 Network 2.8.1 Network Settings Click [Start]  [Menu]  [Network Manage]  [Basic Settings] to set the network: [IP Address] The default IP address is 192.168.1.86. [DHCP] Enable the DHCP to obtain an IP address automatically. If it is enabled, the device will search for a DHCP server, and then assigned a dynamic IP address.
  • Page 15 2. Scan the QR code for “APP” to download and install the application on your smart phone. Note: Support both Android and IOS system. 3. Run the application, then go to the “Device Management” interface and press the button ‘+’ to add a new device.
  • Page 16 PC Application Access 1. Install CMS on your computer. 2. Enter [Resource Management]  [Device Manage] to search, add, delete, modify network devices. Input the device’s name, port, IP address, account and password to manually add a device. Statement  This manual only describes basic operations of the product.
  • Page 17 © Copyright 2019. ZKTECO CO., LTD. ZKTeco Logo is a registered trademark of ZKTeco or a related company. All other product and company names mentioned are used for identification purposes only and may be the trademarks of their respective owners. All specifications are subject to...
