WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage,personal injury or death.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
.
Do not try to light any appliance.
.
Do not touch any electrical switch
.
Do not use any phone in your building.
.
Immediately call your gas supplier from a neighbors phone.
Follow the gas suppliers instructions
.
If you can not reach your gas supplier call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
Remember, when replacing a part on this appliance, use only spare parts that you can be assured conform
to the safety and performance specification that we require. Do not use reconditioned or copy parts that
have not been clearly authorised by Aga-Ranges.
PLEASE READ THESE INSTRUCTIONS BEFORE USING THIS APPLIANCE
INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE.
CUSTOMER: KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
COMPANION/MODULE
(with Gas Hob)

OWNERS MANUAL

Comprising
Installation & Users
Instructions
Cooking
FOR USE IN USA/CANADA
&
Guide
03/08 EINS 511750

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACMPLP-SI and is the answer not in the manual?

Questions and answers

Related Manuals for AGA ACMPLP-SI

Summary of Contents for AGA ACMPLP-SI

  • Page 1: Owners Manual

    Remember, when replacing a part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Aga-Ranges. PLEASE READ THESE INSTRUCTIONS BEFORE USING THIS APPLIANCE INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE.

  • Page 2: Table Of Contents

    CONTENTS SECTION INSTALLATION LOCATION PRODUCT DIMENSIONS - COMPANION PRODUCT DIMENSIONS - MODULE INSTALLATION CLEARANCE OF COMBUSTIBLE CABINETS TECHNICAL DATA INSTALLATION INSTALLATION - MODULE ONLY ELECTRICAL CONNECTIONS CONNECTING TO GAS - COMPANION PRESSURE TESTING SERVICING - COMPANION & MODULE USERS GUIDE INTRODUCTION SAFETY PRECAUTION AND HINTS APPLIANCE VIEW...

  • Page 3: Installation

    Remember, when replacing a part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Aga-Ranges. CAUTION:...

  • Page 4: Location

    Any opening in the wall behind the appliance and in the floor under the appliance must be sealed. LEVELLING The Aga Companion is designed to stand on a flat surface, however any unevenness may be overcome by packing under the corners of the plinth with a suitable non-combustible material, (up to 1/8”).

  • Page 5: Product Dimensions - Companion

    PRODUCT DIMENSIONS - COMPANION 75mm 595mm (3”) Fig 1 330mm MAX. OVERHEAD CUPBOARD 75mm ”) (3”) APPLIANCE CAN BE CLOSE FITTED TO KITCHEN UNITS UP TO WORK TOP HEIGHT. (13”). 600mm ”) DESN 511616...

  • Page 6: Product Dimensions - Module

    * ELECTRIC AND GAS POWER FLUE MODELS ONLY **POSITION FOR GAS SUPPLY PIPE TO MODULE NOTE: Dimensions for Aga GC3 (3 Oven) are identical to GC (2-Oven). For gas supply connections to Aga GC3 (3 Oven) model - See Fig. 5A. OVERHEAD CUPBOARD...

  • Page 7: Installation Clearance Of Combustible Cabinets

    INSTALLATION CLEARANCES OF COMBUSTIBLE CABINETS ADJACENT TO RANGE (GC3 (3 OVEN) WITH MODULE SHOWN) Fig 2A GC3 - Open Flue Model (with Module) DESN 512438...

  • Page 8: Technical Data

    HOTPLATE NATURAL GAS BURNER TYPE MAXIMUM HEAT INPUT INJECTOR MARKING PRESSURE POINT POSITION: PRESSURE SETTING: BURNER IGNITION: PROPANE BURNER TYPE MAXIMUM HEAT INPUT INJECTOR MARKING PRESSURE POINT POSITION: PRESSURE SETTING: BURNER IGNITION: ELECTRIC GRILL & OVENS GRILL ELEMENT - POWER RATING 2 x 1.05 kW TOP OVEN - POWER RATING 1.5 kW LOWER OVEN (FANNED CONVECTION) - 1.9 kW TYPICAL SECTION VIEW OF BURNER FLAMES...

  • Page 9: Installation

    INSTALLATION CAUTION: THIS INSTALLATION MUST CONFORM WITH LOCAL CODES OR, IN THE ABSENCE OF LOCAL CODES WITH THE NATIONAL FUEL GAS CODE, ANSI Z223.I AND NATIONAL ELECTRICAL CODE ANSI/NFPA 70 (IN CANADA CAN/CGA-B149) AND ONLY USED IN A WELL VENTILATED SPACE, READ THESE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE.

  • Page 10: Installation - Module Only

    Proceed with the main Aga build in accordance with normal practice until a check can be made that the Module front plate and Aga front are the same height and that the distance between the two units has been maintained. If not, adjustment should be made to the...
  • Page 11 15. Secure handrails as shown on Instruction Sheet Page 26. 16. Finally tighten both top plates. Commission the main Aga cooker, as stated in the relevant Installation Instructions and carry out functional tests on each of the features on the Module (See Users Instructions).
  • Page 12 REMOVE 2 FIXING SCREWS Fig 3 Fig 4 (WOK BURNER ONLY) DESN 511645 DESN 511646...
  • Page 13 ”) (1”) Fig 5 - Gas Supply Connections Fig 5A - Aga GC3 (Three Oven Only) Gas Supply Connections (Approximate Positions) ”) NOTE: A special rubber grommet is provided to fill-in the ‘knock-out’ hole in the side panel. Pierce the centre of the grommet and pass the 1/4”...
  • Page 14 Fig 6 ”) 64mm TOP PLATE OF MODULE REMOVED Fig 7 FROM TOP SURFACE OF THE AGA TO LUGS ON FRONT PLATE OF MODULE (5/8”) DESN 511255 DESN 511254...
  • Page 15 Fig 8A BURNER BURNER HEAD ELECTRODE Fig. 8B BURNER HEAD ELECTRODE Fig. 8C BURNER CAP RETAINING LUGS BURNER BURNER RING (WOK BURNER ONLY) DESN 511617 DESN 511618 DESN 511619...

  • Page 16: Electrical Connections

    ELECTRICAL CONNECTIONS Electrical grounding is required on this range. Do Not connect to the electrical supply until the range is permanently grounded. Disconnect the power to the junction box before making the electrical connection. This range must be connected to a grounded, metallic, permanent supply or a grounding connector should be connected to the grounding terminal or wire lead on the range.
  • Page 17 Remove the terminal block cover screws located on the back of the range. Make the four-wire connection following the “Power supply cord method”. Power supply cord method This range is manufactured to use a four-wire power supply cord rated at 250-volts, 30-amperes (See “Four wire electrical connection”) WHITE (NEUTRAL)

  • Page 18: Connecting To Gas - Companion

    CONNECTING TO GAS - COMPANION CAUTION: ENSURE THAT COOKER IS ISOLATED FROM ELECTRIC SUPPLY The cooker can be installed with an approved flexible connection. Supply piping should not be less than 3/8 I/D Flexiline. Connection is made to the 1/2” NPT female threaded elbow located just below the hotplate level on the near left hand side of the cooker.

  • Page 19: Pressure Testing

    PRESSURE TESTING The maximum gas inlet pressure to the appliance must not exceed 12” wg for N.G. and 14” for L.P. Gas. The minimum gas inlet pressure at the appliance must not be less than 4” w.g. Natural Gas and 10” wg L.P. Gas to enable the correct manifold pressure to be obtained. NOTE: The regulator is pre-set for either N.G.

  • Page 20: Servicing - Companion & Module

    AGA COMPANION/MODULE (with Gas Hob Unit) DISCONNECT FROM ELECTRICITY SUPPLY BEFORE SERVICING. WHEN REWIRING ANY ELECTRICITY COMPONENTS REFER TO CIRCUIT DIAGRAM AND ELECTRICAL SCHEMATIC DIAGRAM ATTACHED BEFORE ELECTRICAL RECONNECTION. CHECK THAT THE APPLIANCE IS ELECTRICALLY SAFE. NOTE: TURN OFF GAS SUPPLY TO COOKER BEFORE SERVICING ANY GAS CARRYING COMPONENTS.
  • Page 21 TO CHANGE IGNITION ELECTRODE Turn off electricity supply. Remove Top Plate and Hotplate (See sections A and B). Disconnect the electrode cable from the ignition generator. Remove spring clip retaining electrode to burner body (See Fig. 13) and remove electrode and cable.
  • Page 22 DESN 511792 SPARK GENERATOR TERMINAL BLOCK Fig. 11...
  • Page 23 Fig. 13 Fig. 14 DESN 511649 DESN 511650...
  • Page 24 GAS RAIL SUPPORT BRACKET SCREWS Fig. 15 Fig. 16 GAS TAP TUBE NUT GAS RAIL SUPPORT BRACKET SCREWS GAS RAIL TUBE NUT DESN 511651 DESN 511652...
  • Page 25 NOTE: 1. IGNITION SWITCHES AND THERMOSTATS ARE SHOWN 2. THE COOKER IS COLD CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING IN THE OFF POSITION WITH THE APPLIANCE COLD AND FAN OVEN DOOR IS CLOSED.
  • Page 27 END CAP (4) FIBRE PROTECTION END BRACKET (2) WASHERS (2) Prior to fitting the cooker top plate and hot cupboard/electric module top plate to the appliance:- Ensure the self adhesive silicone strip is fitted to the underside of the hot cupboard/electric module overlap to protect the enamel and the jointing bracket fixing plate is fitted to the L.H.

  • Page 28: Users Guide

    Users Guide...

  • Page 29: Introduction

    Any alteration that is not approved by Aga could invalidate the approval of the appliance, operation of the warranty and could affect your statutory rights. In the interests of safety and effective use, please read the following before using your new Aga appliance.

  • Page 30: Safety Precaution And Hints

    SAFETY PRECAUTION AND HINTS Do not store combustible materials, gasoline or other inflammable vapors and liquids near a range cooker. Ensure and maintain the continual free passage of air to the burner housing. Do not stand obstacles against burner outer door and loose hair from dogs or cats must not be allowed to accumulate behind the outer burner door.

  • Page 31: Appliance View

    SEMI RAPID BURNER GAS HOTPLATE RAPID BURNER WOK BURNER SEMI RAPID BURNER CONTROL PANEL REMOVABLE LINER GRILL PAN WITH GRID GRILL & CONVENTIONA L OVEN GRID SHELF FANNED OVEN ROASTING TIN (BAKING TRAY NOT SHOWN) FOR USE IN BOTH OVENS DESN 511635 Fig 17...

  • Page 32: Control Panel

    GAS HOB BURNERS REAR FRONT LEFT LEFT Fig. 18 The GAS HOTPLATE CONTROL KNOBS can only be rotated anti-clockwise from the OFF position. Large Flame Symbol - High Setting Small Flame Symbol - Low Setting (See ‘HOTPLATE’ section). The GRILL ELEMENT KNOB can be rotated in any direction. Clockwise Anti-clockwise The OVEN KNOBS can only be rotated clockwise from the OFF position.

  • Page 33: Gas Hotplate

    The hotplate has four gas burners:- rear left - rapid burner - rated at 3.25 kW/11,000 Btu/hr front left and rear right - semi rapid burner - each rated at 1.8 kW/6,150 Btu/hr front right - ultra rapid (wok) burner - rated at 3.5 kW/12,000 Btu/hr The semi rapid burners are especially suited for use with small pans and for gentle simmering or poaching.
  • Page 34 Deep Fat Frying Use a deep pan large enough to completely cover the appropiate heating area. Never fill the pan more than one-third full of fat or oil. Never leave fat or oil unattended during the heating or cooking period. IMPORTANT: Oil is a fire risk, do not leave pans containing oil unattended.

  • Page 35: The Grill & Ovens

    THE BROILER (TOP OVEN) THE TOP OVEN DOOR MUST BE KEPT OPEN WHEN THE GRILL IS ON. CAUTION: Accessible parts may be hot when the grill is in use. Young children should be kept away. The grill has 5 heat settings on each of 2 elements (see control panel). For best results pre-heat at a high setting.
  • Page 36 If you also have an Aga DO NOT use the small roasting tin provided with the Aga in the Companion/Module. Please use utensils provided and place on the grid shelves.

  • Page 37: Oven Cooking Guide

    OVEN COOKING GUIDE Cooking Hints Pre-heat selected oven until the neon light goes out. The guidelines are for cooking after the oven (s) have reached the desired temperature. Larger items may benefit from being turned. Shelf positions are counted from the top. Put dishes in the centre of the shelf.
  • Page 38 Top Oven (Conventional) The cooking charts are a general guide but times and temperatures may vary according to individual recipes. The meat sections should be used as a guide but may vary according to the size, shape of meat on or off the bone. Thaw frozen pieces of meat thoroughly before cooking them.
  • Page 39 Top Oven (Conventional) • Top Oven (Conventional) • Top Oven (Conventional) • Top Oven (Conventional) • Top Oven (Conventional) FOOD SETTING °F Cakes and Biscuits Cakes and Biscuits Shortbread Very Rich Fruit Cake Fruit Cake Fruit Cake Small Cakes Small Cakes Scones Scones Victoria Sandwich...
  • Page 40 Lower Oven (Fanned/Convection) The lower oven is fanned or a convection oven, which means the air is circulated to create an even temperature throughout the oven. In most cases this means that food requires a lower temperature when cooked in this oven, by approximately 10º...
  • Page 41 L o w e r O v e n ( F a n n e d ) • L o w e r O v e n ( F a n n e d ) L o w e r O v e n ( F a n n n e d ) • L o w e r O v e n ( F a n n e d ) L o w e r O v e n ( F a n n e d ) FOOD SETTING °F Cakes and Biscuits...

  • Page 42: Cleaning & Caring For Your Cooker

    Surfaces that require cleaning are: Enamelled Top and Front The easiest way to clean the Aga Companion/Module top and front plate is to mop up spills as they happen. Baked on food is more difficult to clean but can usually be removed with proprietary vitreous enamel cleaners or mild cream cleaners using a cloth, or if necessary, a nylon scouring pad.
  • Page 43 Heat-Clean Enamel Fan Oven, Conventional Oven, Simmering Oven: sides, top and back Grill Compartment: sides and back This special enamel has a continuous cleaning action, which works best if a pattern of low and high temperature cooking is followed. By using low temperature roasting, excessive fat splashes can be avoided.
  • Page 44 Fig 19A BURNER BURNER ELECTRODE Fig 19B BURNER HEAD ELECTRODE Fig 19C- WOK BURNER ONLY HEAD BURNER CAPS RETAINING LUGS DESN 511617 DESN 511618 BURNER BURNER RING DESN 511619...

  • Page 45: Servicing

    SERVICING In the event of your appliance requiring maintenance, please contact your authorised distributor. Your cooker must only be serviced by a Qualified Engineer, from an authorised distributor Do not alter or modify the cooker. Only the spares specified by the manufacturer, are to be fitted.
  • Page 48 For further advice or information contact your local distributor/stockist With Aga’s policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any time. Aga-Ranges 110 Woodcrest Road Cherry Hill, NJ 08003 800.633.9200...
