ADTRAN, Inc.
Attn: Enterprise Networks
901 Explorer Boulevard
Huntsville, AL 35806
P.O. Box 140000
Huntsville, AL 35814-4000
256 963-8000 voice
256 963-8699 fax
256 963-8200 fax back
General Information
800 9ADTRAN
info@adtran.com
www.adtran.com
Pre-Sales
Technical Support
800 615-1176 toll-free
application.engineer@adtran.com
www.adtran.com/support
Where to Buy
877 280-8416 toll-free
channel.sales@adtran.com
www.adtran.com/where2buy
Post-Sales
Technical Support
888 423-8726
support@adtran.com
www.adtran.com/support
ACES Installation &
Maintenance Service
888 874-ACES
aces@adtran.com
www.adtran.com/support
International Inquiries
256 963 8000 voice
256 963-6300 fax
international@adtran.com
www.adtran.com/international
For the regional office
nearest you, visit:
www.adtran.com/regional
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
61200422L1-8C 11.1 December 2005
Copyright© 2005 ADTRAN, Inc.
All rights reserved.
NetVanta
340
®
Business Class ADSL/ADSL2/ADSL2+ Router
Physical Interface
WAN: ADSL/ADSL2/ADSL2+ Interface
ADSL ITU G.992.1 (Annex A)
ADSL ITU G.992.2 (Annex A) G.Lite
Extended Reach ADSL (RADSL)
ADSL2 ITU G.992.3 (Annex A)
ADSL2+ ITU G.992.5 (Annex A)
LAN: Auto-sensing 10/100Base-T Full Duplex (RJ-45)
Diagnostics LEDs
Power
DSL
Ethernet
Internet
Memory
RAM: 32 MB
FLASH: 16 MB
Routing
eBGP/iBGP
PPP over ATM (RFC 2364)
OSPF
PPPoE over ATM (RFC 2516)
RIP (v1 and v2)
Classical IP over ATM (RFC 2225)
Demand Routing
AAL5
GRE
PAP and CHAP
IGMP v2
Security
Firewall
Stateful Inspection Firewall
Denial of Service (DoS) Protection
Access Control Lists
Application Level Gateways (ALGs)
Network Address Translation
Basic NAT (1:1) and NAPT (Many:1)
NAT compatible SIP ALG
Secure Management
Multi-level access control
RADIUS AAA
TACACS+
SSH CLI and SSL GUI
Optional Virtual Private Network (VPN)
IPSec Mode: Tunnel
Encryption: DES, 3DES, and AES
Diffie Hellman Group Support: Group 1: MODP 768
and Group 2: MODP 1024
Hash Algorithms: MD5-HMAC and SHA1-HMAC
Authentication Mechanisms: XAUTH, Digital
certificates, Preshared keys, and Secure ID
Key Management: IKE (ISAKMP/Oakley)
IKE Modes: Main and Aggressive
Dead Peer Detection
NAT Traversal V2
Specifications subject to change without notice. ADTRAN and NetVanta are
registered trademarks of ADTRAN, Inc. All registered trademarks and trade-
marks mentioned in this publication are the property of their respective owners.
DHCP
Client, Server, and Relay
Administration
Familiar Command Line Interface (CLI)
Web-based GUI
n-Command
™
support
SNMP v2
SYSLOG Logging
Email Alerts (SMTP)
Policy Statistics
Quality of Service
Low Latency, Weighted Fair Queuing (WFQ), and
Classed-based WFQ
DiffServ Packet Marking and Recognition
Frame Relay Fragmentation
Environment
Operating Temperature: 0° to 50 °C (32° to 122 °F)
Storage Temperature: -20° to 70 °C (-4° to 158 °F)
Relative Humidity: Up to 95%, non-condensing
Physical
Chassis: Self-standing, plastic enclosure
Dimensions: 1.625" H, 7.5" W, 5.25" D
Weight: 1 lb.
Power: 100–250 VAC, 60 Hz, 65 mA, 8 W max.
Agency Approvals
FCC Part 68
Industry Canada CS03
UL & Canadian UL (CUL), IEC/EN, CSA
Ordering Information
Equipment
Systems
NetVanta 340 Chassis
Systems with VPN
NetVanta 340 Chassis with VPN
VPN Software Upgrade
NetVanta VPN Software Upgrade
Network Management
n-Command, ADTRAN's
new comprehensive network
management software for NetVanta-based
networks. For a flash demo and a
free software download, visit:
www.adtran.com/n-command
Part #
1200422L1
4200422L2
1950422L2
