ADTRAN NetVanta 3448 Quick Start

Quick Start
G S
ETTING TARTED
This NetVanta unit ships with a statically assigned IP address of 10.10.10.1 and the ability
to connect to a Dynamic Host Control Protocol (DHCP) network and receive an IP address
assignment from a DHCP server. When connecting to a DHCP network, this unit supports
Zero-Touch Provisioning, allowing the NetVanta router to download and apply configuration
parameters from a configuration management server.
Regardless of the method you use to connect the NetVanta unit to the network, there are
two methods available for configuration:
■ Web-based graphical user interface (GUI)
■ ADTRAN Operating System (AOS) command line interface (CLI)
The GUI lets you configure the main unit settings and provides online guidance and expla-
nations for each setting. However, using the AOS CLI may be necessary for more
advanced configurations.
A
CCESS THE
You may access the GUI from a web browser in one of two ways:

Connect via the Static Address

1. Connect the router to your PC using the switch port labeled 1 on the back of the unit.
2. Set your PC to a fixed IP address of 10.10.10.2. To change your PC IP address,
navigate to Computer > Control Panel > Network Connections > Local Area
Connection > Properties > IP (TCP/IP) and select Use this IP Address. Enter these
parameters:
■ IP Address: 10.10.10.2
■ Subnet Mask: 255.255.255.0
■ Default Gateway: 10.10.10.1
You do not need to enter any DNS server information. After the information is entered,
select OK twice, and close the Network Connections dialog box. If you cannot change
the PC's IP address, you will need to change the unit's IP address using the CLI.
(Refer to the next two sections for instructions.)
3. Open a web browser and enter the unit's IP address in your browser address line as
follows: http://10.10.10.1. The default IP address is 10.10.10.1, but if you had to
change the unit's IP address using the CLI, enter that address in the browser line.
4. The initial GUI screen appears.

Connect via the DHCP Client Address

1. Connect the router to an existing network that supports DHCP using the switch port
labeled 1 on the back of the device. The NetVanta unit will automatically request an IP
address assignment from the DHCP server.
61200821F1-13B
NetVanta
NetVanta 3448 Router
GUI
October 2018
61200821F1-13B
P/N: 1200821F1
1
