Operator's Manual – Spider CROSS LINER
REMOTE CONTROLLED MOWER SPIDER
OPERATOR´S MANUAL
SPIDER CROSS LINER and SPIDER CROSS LINER lite
th
5
Edition – 2020
S.N. 148 -
Product´s production number
Engine type
Engine´s production number
DVOŘÁK – svahové sekačky s.r.o.
Pohled 277, 582 21 Pohled, Czech Republic
+420 564 036 099, info@spider-cz.com,
www.spidermower.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CROSS LINER and is the answer not in the manual?

Questions and answers

Related Manuals for SPIDER CROSS LINER

Summary of Contents for SPIDER CROSS LINER

  • Page 1 Operator’s Manual – Spider CROSS LINER REMOTE CONTROLLED MOWER SPIDER OPERATOR´S MANUAL SPIDER CROSS LINER and SPIDER CROSS LINER lite Edition – 2020 S.N. 148 - Product´s production number Engine type Engine´s production number DVOŘÁK – svahové sekačky s.r.o. Pohled 277, 582 21 Pohled, Czech Republic +420 564 036 099, info@spider-cz.com,...
  • Page 2 Operator’s Manual – Spider CROSS LINER Notes:...

  • Page 3: Table Of Contents

    Operator’s Manual – Spider CROSS LINER TABLE OF CONTENT INTRODUCTION 1 INSTRUCTIONS 2 EC/EU DECLARATION OF CONFORMITY 3 SAFETY 3.1 SAFETY WARNINGS ......................... 8 3.2 SAFETY INSTRUCTIONS ........................9 3.3 SAFETY LABELS ..........................11 4 ABOUT THE PRODUCT 4.1 MAIN COMPONENTS LOCATIONS ....................14 4.2 USE OF THE MOWER ........................
  • Page 4 Operator’s Manual – Spider CROSS LINER 8 TECHNICAL DATA 8.1 FLUIDS, LUBRICANTS AND FILLING VOLUMES ................59 8.2 TECHNICAL DATA ........................... 59 9 TROUBLESHOOTING 9.1 MOWER TROUBLESHOOTING ....................... 61 9.2 WINCH TROUBLESHOOTING ......................62 9.3 REMOTE CONTROL TROUBLESHOOTING ................... 62...

  • Page 5: Introduction

    Operator’s Manual – Spider CROSS LINER INTRODUCTION OPERATING INSTRUCTIONS This manual is an integral part of the mower, keep it clean and in good condition. In case of loss or damage, replace it immediately. Always keep it available with the machine and, if handed over to another owner/operator, please provide the manual as well.

  • Page 6: Instructions

    Operator’s Manual – Spider CROSS LINER INSTRUCTIONS SERIAL NUMBER In this manual you will find information about the SPIDER CROSS LINER and SPIDER CROSS LINER lite Applies to all models starting with serial number 148. MANUFACTURER’S ADDRESS DVOŘÁK – svahové sekačky, s.r.o.,...

  • Page 7: Ec/Eu Declaration Of Conformity

    Product (Machine) – Type: Mower SPIDER CROSS LINER Serial number: Description: SPIDER CROSS LINER is a remote-controlled mower designed for mowing and mulching grasslands on normal and sloping terrain. We declare that the machinery fulfils all the Directive 2006/42/ES, NV č. 176/2008 Sb.

  • Page 8: Safety

    If you do not understand the warning messages, ask your employer or SPIDER distributor / dealer for an explanation. Please be aware that security is not just a matter of responding to a given alert. You must keep in mind the possible hazards and try to avoid them for the duration of the work on or with the product.

  • Page 9: Safety Instructions

    Operator’s Manual – Spider CROSS LINER SAFETY INSTRUCTIONS • Do not enter or reach under the machine if it is lifted and not sufficiently supported. The machine should be supported on places marked by the symbol of a lifting jack.
  • Page 10 Operator’s Manual – Spider CROSS LINER • While operating the mower avoid obstacles, do not drive over higher obstacles (such as stones, stumps, brick), near precipices, on unstable soil or in places where the mower could fall down or flip over.

  • Page 11: Safety Labels

    Operator’s Manual – Spider CROSS LINER • The working position should be far enough (maximum 50 m / 165 ft.) to prevent the operator from getting hit by objects that may be accidentally thrown by the mower. • Do not operate the mower if you cannot see it (behind terrain obstacles, corners of buildings, hidden in grass etc.) •...
  • Page 12 Operator’s Manual – Spider CROSS LINER SAFETY LABEL IDENTIFICATION Description Label Height of cut label Fuel label Safe operating distance Danger of being hit by flying objects No manipulation with moving parts until the whole system is stopped Warning, do not use your hands as...

  • Page 13: Figure 6 - Safety Labels

    Operator’s Manual – Spider CROSS LINER Correct winding direction of the rope Wrong direction for rope winding When winding / unwinding, keep the rope tightened Read the manual before handling Risk of dragging fingers and hand palm into the machine...

  • Page 14: About The Product

    Operator’s Manual – Spider CROSS LINER 4 ABOUT THE PRODUCT MAIN COMPONENT LOCATION FUEL TANK CAP SAFETY BEACON FUEL TANK CAP BEZPEČNOSTNÍ MAJÁK CENTRAL STOP CENTRAL STOP INTAGRATED STABILIZING WINCH* REMOTE CONTROL INTAGRATED STABILIZING WINCH REMOTE CONTROL Figure 2 – Basic description...

  • Page 15: Use Of The Mower

    Operator’s Manual – Spider CROSS LINER USE OF THE MOWER The mower is designed to be used for mowing grasslands on flat and sloping terrain under normal conditions. The mower's work normally involves mowing or mulching while driving forward, backward and turning. The mower is operated by one person via a remote radio controller.

  • Page 16: Prohibited Use

    Operator’s Manual – Spider CROSS LINER PROHIBITED USE • The mower must not be used for any purpose other than that for which it is intended. • The mower must not be used on areas with glass particles, stones, iron or other unwanted objects that may be thrown by the rotating blade or which may damage the mower.

  • Page 17: Remote Controller (Rc)

    Operator’s Manual – Spider CROSS LINER REMOTE CONTROLLER (RC) CENTRAL STOP Two red colored CENTRAL STOP buttons are used to switch the mower off. One is located on the mower (1), the other on the remote control (RC) (2). 1 – CENTRAL STOP on the mower 2 –...

  • Page 18: Figure 7 - Remote Controller

    Operator’s Manual – Spider CROSS LINER REMOTE CONTROLLER ENGINE’S RPM DRIVING SPEED CONTROL RANGE RABBIT/TURTLE DRIVING SPEED ENGINE’S RPM ACTIVATION RANGE SKID CONTROL SWITCH RABBIT/TURTLE STEERING ACTIVATION SKID SWITCH STEERING MOWING DECK – MAIN SWITCH BLADE ON/OFF SWITCH MAIN SWITCH ENGINE START/STOP MOWING DECK –...
  • Page 19 Operator’s Manual – Spider CROSS LINER LIGHT SIGNALS The remote radio has two LEDs near the STOP button. LED RED LED GREEN LED RED LED GREEN LED GREEN LED RED MEANING Controller is OFF Flashing intensively Controller and receiver are not connected.

  • Page 20: Operation

    Operator’s Manual – Spider CROSS LINER 5 OPERATION The aim of this handbook is to guide the operator get familiarized, step by step with the use of the mower so that it can work efficiently and safely. Read the OPERATION chapter from start to finish.
  • Page 21 Operator’s Manual – Spider CROSS LINER Workplace Driving at high speeds Workplaces can be dangerous. Before starting work, Driving at high speeds can lead to accidents. Do not your work area will need to be properly examined. move the joystick as far as possible. Always drive at a You could be seriously hurt or even killed if the soil safe speed that suits your working conditions.
  • Page 22 Use carbon dioxide, dry ice or foam local SPIDER distributor / dealer who will be happy to fire extinguishers. Contact the nearest fire station as provide you with the necessary information. Below is soon as possible.

  • Page 23: Mower Check Up

    Operator’s Manual – Spider CROSS LINER MOWER CHECK UP The following checks must be carried out after each prolonged break with the mower. They are also recommended for longer continuous work with the mower, i.e. to stop the mower from time to time and carry out the check.

  • Page 24: Stopping And Parking

    Operator’s Manual – Spider CROSS LINER Press the activation switch on the controller. ACTIVATION SWITCH ACTIVATION SWITCH Hold the switch to the start position and hold it in this position until the engine starts. ENGINE START/STOP SWITCH After starting the engine, set the engine speed to maximum.

  • Page 25: Driving The Machine

    Operator’s Manual – Spider CROSS LINER 4) Hold the switch to the engine OFF position. ENGINE STOP VYPNUTÍ MOTORU CENTRAL STOP 5) Press the CENTRAL STOP on the mower. CENTRAL STOP 6) Switch off the remote controller by turning the main switch.

  • Page 26: Cutting Blade On/Off

    SPIDER MODE The mower is equipped with a unique SPIDER mode control system (also known as the “dance step”), thanks to which all 4 wheels turn at full 360°, so there is no need to rotate the machine if you need to change direction.

  • Page 27: Mowing Height Adjustment

    Operator’s Manual – Spider CROSS LINER MOWING HEIGHT ADJUSTMENT The machine has 4 cutting height adjustment positions. The mowing height can be set as standard in the range between 40 - 110 mm. To set the cutting height: 1) Stop the mower on a horizontal surface and turn off the mowing deck.

  • Page 28: Hydraulic Stabilizing Winch

    Operator’s Manual – Spider CROSS LINER HYDRAULIC STABILIZING WINCH* The mower is equipped with an integrated stabilizing hydraulic winch (hereinafter referred to as "winch"), which is designed as a stabilizing device and improves the mower stability on slope. It also prevents the mower from sliding downhill and reduces soil erosion.

  • Page 29: Figure 8 - Main Components Of The Hydraulic Winch

    Operator’s Manual – Spider CROSS LINER MAIN COMPONENTS CONTROL LEVER CONTROL LEVER CARABINER WINCH BODY CARABINE WINCH BODY GUIDING FRAME ROPE Figure 8 – main components of the hydraulic winch GUIDING FRAME ROPE WINCH CONTROL POWER ON To switch the winch on, set the valve lever to position 1 to activate the hydraulic oil inlet to the winch hydraulic motor.

  • Page 30: Figure 9 - Method Of Mowing On The Slope With Use Of The Winch

    Operator’s Manual – Spider CROSS LINER 4) Set the valve lever to position 1 (ON). 5) Slightly deflect the driving joystick on the remote controller in the direction in which the rope starts to unwind from the drum. (The winch is pre-set to unwind when the driving joystick is deflected in the BACKWARD direction – towards the operator. In case the rope winds up instead of unwinding, deflect the joystick in the opposite direction.)

  • Page 31: Refueling The Machine

    Operator’s Manual – Spider CROSS LINER EMERGENCY SITUATIONS WHEN WORKING ON THE STABILIZING WINCH EMERGENCY SITUATION RECOMMENDED SOLUTIONS A rope or anchor is suddenly Turn the wheels immediately so that they are perpendicular to the slope (across to the slope), stop the movements. Find a new anchor point. Press the STOP button released on the remote control.

  • Page 32: Operating Conditions

    Operator’s Manual – Spider CROSS LINER Always fill the fuel tank at the end of the work shift. This will prevent condensation on the tank walls. FILLING THE FUEL TANK 1) Secure and turn off the mower engine by pressing the CENTRAL STOP.

  • Page 33: Storage

    Operator’s Manual – Spider CROSS LINER 6 STORAGE CLEANING WARNING When using cleaning fluids, solvents or other chemicals, you must follow the manufacturer's instructions and precautions. WARNING Wear protective gloves when handling hot parts to prevent burns. To protect your eyes, wear eyeglasses when cleaning parts with a wire brush.

  • Page 34: Mower Transportation

    Operator’s Manual – Spider CROSS LINER SEASON PREPARATION 1) Check all fluid levels. If necessary, top off to the recommended level. 2) Clean the mower and remove any unwanted material and corrosive products. Dry the mower to remove solvents and moisture.

  • Page 35: Maintenance

    DVOŘÁK – svahové sekačky s.r.o. spare parts catalog has been prepared in the partner zone website, where you will find individual spare parts and aids that you can order from your local Spider dealer for your mower type. When ordering spare parts, you must tell our representative exactly the model of the mower and its serial number.

  • Page 36: Maintenance Safety

    Operator’s Manual – Spider CROSS LINER MAINTENANCE SAFETY Compressed air operation. Allow the engine and components to cool Compressed air is dangerous. Always wear personal down before servicing. protective equipment. Never aim the compressed air nozzle at yourself or others.
  • Page 37 MANIPULATION WITH OILS ATTENTION The hydraulic oil temperature will be high right after the engine stops. Wait until it has cooled down before starting maintenance. New oil There are no special precautions necessary for handling or using new oil in addition to routine care and hygiene procedures.

  • Page 38: Maintenance Schedule

    Operator’s Manual – Spider CROSS LINER MAINTENANCE SCHEDULE The maintenance schedule is based on the number of hours the mower is running, except for daily maintenance. It Obrázek 4 – Poloha skeletu žacího ústrojí při servisní poloze is therefore necessary to regularly check the number of hours worked and to determine service intervals accordingly.
  • Page 39 Operator’s Manual – Spider CROSS LINER MOWER MAINTENANCE CHART First Every 3 Every 6 Every X = Operator Month Months Months Year Each Every S = Authorized service Year * = in dusty areas to be performed more frequently 20 Hrs...

  • Page 40: Mower Service Positions

    Operator’s Manual – Spider CROSS LINER MOWER SERVICE POSITIONS VERTICAL SERVICE POSITION The vertical service position is used for cleaning and maintenance of the cutting device. The mower must be placed in this position on a firm and level surface only for the duration of the service.
  • Page 41 Operator’s Manual – Spider CROSS LINER HORIZONTAL SERVICE POSITION PROCEDURE: Place the mower on a level and solid surface. Switch off the mower and the remote control. Unlock and adjust the cutting height lever to the lowest possible level so that the mowing platform pushes against the floor and lifts the wheels off the ground, then secure the lever again.

  • Page 42: Service Points

    Operator’s Manual – Spider CROSS LINER SERVICE POINTS ENGINE AREA OIL FILLER CAP/ DIPSTICK SPARK PLUG OIL DRAIN PLUG ELECTRIC STARTER AIR CLEANER CONTROL FUEL VALVE LEVER LEVER WARNING Dust particles in the air or light explosive material (e.g. straw, grass, sawdust, etc.) must not accumulate in the engine and exhaust area.

  • Page 43: Figure 12 - Service Points - Mower

    Operator’s Manual – Spider CROSS LINER MOWER – SERVICE POINTS HEIGHT OF CUT HANDLE CONTROL UNIT MADLO ZDVIHU CONTROL WHEEL UNIT PORTAL PORTÁL CHASSIS FUEL TANK WINGS FUEL SYSTEM KŘÍDLA HYDRAULIC TANK HYDRAULIC WINCH GUIDE SYSTEM STABILIZING WINCH STABILIZING WINCH...

  • Page 44: Geometry Adjustment

    Operator’s Manual – Spider CROSS LINER GEOMETRY ADJUSTMENT The geometry is adjusted mechanically. The mower operator evaluates whether the geometry needs to be adjusted or not. If you do not have the necessary equipment and experience, have this work done by a specialist.
  • Page 45 Operator’s Manual – Spider CROSS LINER GEOMETRY ADJUSTMENT FOR MACHINES WITHOUT SKID-STEERING Place the mower in a horizontal service position so that the frame is in contact with the floor and the wheels are freely above the ground. Turn so that the wheels of one of the sides are level when the batten is placed against.

  • Page 46: Engine Maintenance

    Operator’s Manual – Spider CROSS LINER ENGINE MAINTENANCE The activities listed below are considered workshop maintenance and should only be performed by trained personnel. Before starting any maintenance work on the mower, switch off the engine and allow it to cool down, press the CENTRAL STOP emergency button on the mower and remove the key.
  • Page 47 Operator’s Manual – Spider CROSS LINER WARNING When topping off, the oil must not get on hot parts of the engine - risk of fire. Read and follow the warnings before working in the engine area. ENGINE OIL CHANGE Engine oil must be replaced at the intervals specified in the engine maintenance schedule. See also:...
  • Page 48 Operator’s Manual – Spider CROSS LINER ENGINE AIR FILTER A dirty air cleaner will restrict air flow to the carburetor, reducing engine performance. If you operate the engine in very dusty areas, clean the air filter more often than specified in the MAINTENANCE SCHEDULE.
  • Page 49 Operator’s Manual – Spider CROSS LINER SPARK PLUG Recommended Spark Plug: BPR5ES (NGK) ATTENTION An incorrect spark plug can cause engine damage. For good performance, the spark plug must be properly gapped and free of deposits. Disconnect the spark plug cap, and remove any dirt from around the spark plug area.

  • Page 50: Fuel System

    Operator’s Manual – Spider CROSS LINER FUEL SYSTEM CLEANING THE FUEL TANK While the mower is in use, dirt may accumulate in the fuel tank, which may cause the fuel system to clog up when the mower is operating. The tank may only be emptied by suctioning petrol, taking all precautions when handling fuel.

  • Page 51: Hydraulic System

    Operator’s Manual – Spider CROSS LINER GRINDING AND INSPECTION OF THE CUTTING BLADE To check the blade geometry: • the blade must not be bent • never straighten a bent blade, USE NEW! • the ends of the knife must be flush (test whether the whole surface is on a flat surface) Grinding: •...

  • Page 52: Hydraulic Stabilizing Winch

    Operator’s Manual – Spider CROSS LINER CHECKING FOR OIL LEAKAGE Check the hydraulic hoses for damage. Check all hydraulic functions. In particular, check the speed of operation, vibrations and abnormal sounds. Do not use the mower where one or more of these defects appear.

  • Page 53: Electrical System

    Operator’s Manual – Spider CROSS LINER 7.11 ELECTRICAL SYSTEM CONTROL UNIT Normal mode Under normal conditions, the mower operates in normal mode. The mower fully responds to all external stimuli and user control. All safety functions are switched on. Normal mode is exited if a serious error occurs or service mode is intentionally started.
  • Page 54 Operator’s Manual – Spider CROSS LINER FUSES Electrical circuits are protected by a fuse (32V, 40A). If the fuse blows, find out why this occurred before installing a new one. The fuse and spare fuse are located in the control unit.

  • Page 55: Neutral Position Adjustment

    Operator’s Manual – Spider CROSS LINER BATTERY TESTING The best and easiest way to test the battery is to use a voltmeter or a multimeter to measure the resting voltage. If you know the exact voltage, use the table below to determine the charge.

  • Page 56: Figure 20 - Mowing Device

    Operator’s Manual – Spider CROSS LINER 5) Check the pulley's brake belt for wear, the belt for wear, and the nuts and bolts for proper tightening. 6) If the tension is insufficient or the belts and the braking belt are worn, have the belt replaced or the tensioning mechanisms adjusted by an authorized dealer or service center.

  • Page 57: Lubrication

    Operator’s Manual – Spider CROSS LINER CHAIN TENSIONER NAPÍNACÍ KLADKA DRIVE BELTS ŘETĚZU ŘEMEN POJEZDU STEERING CHAIN ŘETĚZ NATÁČENÍ BELT TENSIONER NAPÍNACÍ KLADKA ŘEMENU Figure 22 - Drive 7.14 LUBRICATION Apply a reasonable amount of lubricant to the parts to be lubricated. Excessive amounts of lubricant cause leakage and contamination of the mower and the environment.

  • Page 58: Tire Pressure

    Operator’s Manual – Spider CROSS LINER 7.15 TIRE PRESSURE Observe the recommended tire pressure. Other values may adversely affect handling, especially on slopes. In some cases, you may also lose control of the mower. Recommended tire pressure: Turf tires: max. 200 kPa – 2,0 bars X-track tires: max.

  • Page 59: Technical Data

    Operator’s Manual – Spider CROSS LINER 8 TECHNICAL DATA FLUIDS, LUBRICANTS AND FILLING VOLUMES WARNING In the event of any unauthorized fuel types (or their equivalents) being used at any time, the producer rejects any liability for engine failure. Item...
  • Page 60 Operator’s Manual – Spider CROSS LINER NOISE EMISIONS The mower emits the following noise: Sound power LWA = 95,8 dB Guaranteed sound power level LWA = 98 dB The measurement was carried out according to ISO 3744 60/66...

  • Page 61: Troubleshooting

    Operator’s Manual – Spider CROSS LINER 9 TROUBLESHOOTING MOWER TROUBLESHOOTING Failure Probable cause Repair Travel joystick is not in the neutral Move joystick to the neutral position position The mower blade lever is in the “on” Move mower blade lever to the “off” position...

  • Page 62: Winch Troubleshooting

    Operator’s Manual – Spider CROSS LINER Not able to turn on Check the condition of the belts or replace / consult a Loose cutting belts the blade service center Not able to turn the Worn or non-trimmed mower deck Consult a service center...
  • Page 63 Operator’s Manual – Spider CROSS LINER Control start up, the green LED is off the red LED¹ has TWO long blinks³. At Radio Remote Control start up, the green LED is off The battery needs to be replaced The battery is very low.

  • Page 64: Warranty Conditions

    (“Spider”) to the original purchaser of new equipment from Spider or authorised Spider Distributors/Dealers. Under these warranties Spider will repair or replace, at its opinion, any covered part which is found to be defective in material or workmanship during the applicable warranty term. Warranty service must be performed by a Distributor/Dealer or service centre authorised by Spider to sell and/or service the type of equipment involved, which will use only new or remanufactured parts or components furnished by Spider.
  • Page 65 11. The selling Distributor/Dealer has no authority to make any warranty, representation, condition or promise on behalf of Spider, or to modify the terms or limitations of this warranty in any way and makes no warranty on any other item unless it delivers to the purchaser a separate written certificate specifically warranting the item.
  • Page 66 Operator’s Manual – Spider CROSS LINER Shortcuts: RRC (RC) Radio Remote controller Mower Spider XLINER Figures: Figure 1 – Identification of the mower Figure 2 – Basic description Figure 3 – Basic description Figure 4 – Maximum slope Figure 5 – Hazardous zones Figure 6 –...
