- Page 1 Manual No.: Parameterisation manual MWF-PA102 Microwave level measurement Index Date Adaption of parameters with the MWF2-KIT Page 1 of 9 08.08.18 HART modem with mA-display Parameterisation manual...
- Page 2 Page 2 of 9 08.08.18 Preparation Requirements: MOLLET MWF2-KIT, a Laptop or PC with Microsoft Windows 7, 8, 10 and Excel. The MOLLET MWF2-KIT consists of: - 1 MWF-HART-D2 modem with mA-display (see first page) - 1 measuring wire A with blank end of the wire...
- Page 3 Manual No.: Parameterisation manual MWF-PA102 Microwave level measurement Index Date Adaption of parameters with the MWF2-KIT Page 3 of 9 08.08.18 Connection to the MWF electronic There are two possibilities to connect the MWF-HART-D2 modem with the MWF electronic: 1.1.1 Connection direct to the device: Separate the MWF electronic temporary from the power supply.
- Page 4 In order to secure your changes please store the Excel-file on the connected PC. With it the changed parameters can be checked again at any time or the Excel-file can be sent to MOLLET for support. During the process of parameterisation you can use the display on the MWF-HART-D2 modem for monitoring the current output (4 –...
- Page 5 Manual No.: Parameterisation manual MWF-PA102 Microwave level measurement Index Date Adaption of parameters with the MWF2-KIT Page 5 of 9 08.08.18 Line 14 and 15 Setting of upper dead band [TB] Dependent on the installation situation of the MWF signal disturbances could occur in the upper area of the measuring probe (e.g.
- Page 6 2 as well. Line 27 Reset to MOLLET factory settings Click on START in line 27 and the MWF will be reset to MOLLET factory settings. All individual parameter settings will be overwritten with the primary MOLLET factory settings. Line 28 Measuring of filling level Click on START in line 28 and the actual filling level will be scanned.
- Page 7 READ ON or OFF Line 26 Read out probe length [L] click READ Line 27 Reset to MOLLET factory settings click START Line 29 Read out software version click READ Line 30 Read out device status (only for internal use)
- Page 8 Manual No.: Parameterisation manual MWF-PA102 Microwave level measurement Index Date Adaption of parameters with the MWF2-KIT Page 8 of 9 08.08.18 Signal images Examples of signal images useful for comparison with recorded signal images from you. 4.1 Signal image of an empty silo. Wave runs through without any significant signal up to the tensioning weight.
- Page 9 Manual No.: Parameterisation manual MWF-PA102 Microwave level measurement Index Date Adaption of parameters with the MWF2-KIT Page 9 of 9 08.08.18 4.3 Signal image with weak signal without indication of filling level. A weak signal is indicated at approx. 1850mm, but no filling level is indicated or the filling level indication varies.
