alphatronics AlphaCom PSTN-2-IP ML Installation Manual page 9

AlphaCom PSTN2IP ML PROGRAMMING
The AlphaCom PSTN2IP ML can now be programmed. Set the laptop‟s IP address to 192.168.0.49 and the
subnet mask to 255.255.255.0. The gateway address can be left empty.
Now start up your Internet browser and type in the address field 192.168.0.48. The login screen will now
appear. Follow the programming instructions as described at page 13.
Set dipswitches 2 and 3 back after programming and connect a standard (straight) network cable between the
AlphaCom PSTN2IP ML and the router. Reset the AlphaCom PSTN2IP ML by removing the power
connector or by shorting the reset pins. Do not forget to test the reporting to the monitoring station.
Service manual AlphaCom PSTN2IP ML transceiver Rev. 1.6 10-09-2011 Page 9/65
