Technical specifications of the AlphaCom PSTN2IP ML transceiver:
Dimensions:
Power consumption standby:
Power consumption operational:
Power supply:
Operating temperature:
LAN connection:
Ordering code:
The AlphaCom PSTN2IP ML transceiver complies with the following European standards:
EMC immunity
Radio
Telephone
Security Class
Alarm transmission
ATS classes 50136-1-1
*)
the PSTN connection complies with the TBR21 norm, but is not connected to the public telephone
exchange network. The PSTN connection generates its own telephone line signals that imitate the signals of
a public exchange network, this makes it possible to receive alarm messages from the control panel that is
connected tot the PSTN connection and send them through an IP connection.
**) see chapter „Settings according to local requirements‟ for the correct settings of this device according to
the required local regulations for this specific installation. Also here you will find the settings for the dutch
regulations according to the AL1, AL2 and AL3 norm.
The AlphaCom PSTN2IP ML is manufactured with the most modern production methods and complies with
RoHS regulations. This means that components used and the soldering procedures are lead-free.
Alphatronics b.v.
Watergoorweg 71
3861 MA Nijkerk
The Netherlands
Telephone: +31 33-2459944
Fax: +31 33-2453149
Web: www.alphatronics.nl
E-mail: info@alphatronics.nl
Service manual AlphaCom PSTN2IP ML transceiver
157 x 96 x 18 mm (l x w x h).
115mA.
210mA.
12-16 Volt dc
0- +50 C
10 Mbit/s
003611
EN50130-4 2003
EN300220-3
*)
TBR21 1998
European norm EN60950
EN50136-2-1 1998
**)
D4, M4, T5, A3, S2, I3
