Page 1: User Guide
SuperStack Advanced RPS User Guide 3C16071B http://www.3com.com/ Part No. DUA1607-0AAA04 Rev. 01 Published November 2000 ®... - Page 2 LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.
-
Page 3: Table Of Contents
ONTENTS BOUT UIDE How to Use This Guide Conventions Related Documentation Documentation Comments Product Registration NTRODUCING THE About the Advanced RPS Advanced RPS Chassis — Front View Detail LEDs Advanced RPS Chassis — Rear View Detail Power Sockets (Mains AC Power) Power Module Slots Management Module Slot Power Modules... - Page 4 Full Redundancy NSTALLING Unpacking the Advanced RPS Choosing a Suitable Site Rack Mounting Using the Rack Mounting Kit Placing Units On Top of Each Other Installing a Power Module Power Supply and Fuses Connecting the DC Cables Standard DC Cables Optional ‘Y’...
- Page 5 Power Module Usage Units not supported Obsolete Products ROUBLESHOOTING ECHNICAL UPPORT Online Technical Services World Wide Web Site 3Com Knowledgebase Web Services 3Com FTP Site Support from Your Network Supplier Support from 3Com Returning Products for Repair NDEX ORPORATION EGULATORY...
-
Page 7: About This Guide
Most user guides and release notes are available in Adobe Acrobat Reader Portable Document Format (PDF) or HTML on the 3Com World Wide Web site: http://www.3com.com/ UIDE ®... -
Page 8: How To Use This Guide
Safety Information applicable to the Advanced RPS Technical Information about the Advanced RPS. Permitted configurations for the Power Modules. Troubleshooting. How you can contact 3Com for support. Conventions Table 1 lists conventions that are used throughout this guide. Table 1 Notice Icons... -
Page 9: Documentation Comments
Page number (if appropriate) Example: SuperStack 3 Advanced RPS User Guide Part Number DUA1607-0AAA03 Page 21 Product Registration You can now register your SuperStack unit on the 3Com web site to receive up-to-date information on your product: http://support.3com.com/warrantyregistration/register.pl Documentation Comments... - Page 10 BOUT UIDE...
-
Page 11: Introducing The Advanced Rps
NTRODUCING THE This chapter contains introductory information about the SuperStack associated products, and how they can be used to support your SuperStack network devices. It covers the following topics: About the Advanced RPS Advanced RPS Chassis — Front View Detail Advanced RPS Chassis —... -
Page 12: Advanced Rps Chassis - Front View Detail
1: I HAPTER NTRODUCING THE Advanced RPS Chassis — Front View Detail Figure 1 Front View of the Advanced RPS Chassis LEDs The Advanced RPS chassis has LEDs visible on the front panel that indicate the status of the AC power inputs, the power modules, and the temperature of the chassis itself. -
Page 13: Advanced Rps Chassis - Rear View Detail
Table 1 LED behavior Color AC Power Inlet Status LEDs INPUT OK Green A and B Power Module Status LEDs OUTPUT OK Green OUTPUT Yellow FAULT Chassis Temperature Status LED OVERTEMP Yellow Advanced RPS Chassis — Rear View Detail Figure 2 Rear View of the Advanced RPS Chassis Power Sockets (Mains AC Power) The Advanced RPS chassis has two AC mains inputs, labelled Primary Pwr A and Backup Pwr B. -
Page 14: Power Module Slots
AC sources that can be from separate phases. 3Com require that you confirm that your chassis supports the dual phase feature by checking that “3C16071A” or “3C16071B” appears on the serial number label on the base of the chassis, the front panel overlay, and also on the packaging label. -
Page 15: Power Modules
3.3 V through the connector shown in Figure 4. A Type 2 DC power cable is supplied with each module. CAUTION: The Advanced RPS chassis (3C16071A and 3C16071B) does not support the Type 2 Power Module (3C16074). You must use a Type 2A Power Module (3C16074A). -
Page 16: Type 3 (325 W) Power Module - 3C16075
1: I HAPTER NTRODUCING THE Type 3 (325 W) Power Module — 3C16075 This module is suitable for powering a specific range of SuperStack units. See Appendix C for a list of these units. This module provides +27 V through the connector. A Type 3 DC power cable is supplied with each module. -
Page 17: Type 2 Dc Cables
Figure 5 Type 1 DC ‘Y’ Cable (3C16079) Type 2 DC Cables Use a Type 2 DC cable, supplied with each Type 2A Power Module, to connect a Type 2A Power Module to a SuperStack unit. An optional Type 2 ’Y’ DC cable (3C16078) is available to connect two Type 2A Power Modules to a SuperStack unit for full redundancy. -
Page 18: Using The Advanced Rps
1: I HAPTER NTRODUCING THE Figure 7 Type 3 DC ‘Y’ Cable (3C16077) Using the Advanced RPS There are several ways you can use the Advanced RPS to benefit your network and protect against internal PSU failure on your SuperStack units. -
Page 19: Full Redundancy
Using the Advanced RPS The SuperStack unit is supplied with power from an AC mains supply. A power module is connected using the standard DC cable to the RPS socket on the SuperStack unit (see Figure 9). If the internal power supply fails, the SuperStack unit enables the Advanced RPS. - Page 20 1: I HAPTER NTRODUCING THE DVANCED Make sure you use the correct type of ’Y’ cable for the right module combination. See “Power Modules” on page 15 for front views of the different connectors. If one of the power modules fails, the other module will take the full load.
- Page 21 NSTALLING CAUTION: The Type 3 DC Power Module is for installation by suitably qualified service personnel only. Refer to the Type 3 Power Module Installation Guide. This chapter contains the information you need to install and set up the SuperStack topics: Unpacking the Advanced RPS Choosing a Suitable Site...
-
Page 22: Installing The Advanced Rps
Water or moisture cannot enter the case of the unit. Air flow around the unit and through the vents in the side of the case is not restricted (3Com recommend that you provide a minimum of 75-mm (3-in.) clearance). To prolong the operational life of your units: Never stack units more than eight high on top of the Advanced RPS. -
Page 23: Rack Mounting
The rack must be well ventilated — 3Com recommend using an open frame type. 3Com recommend that runners or a tray be fitted in the rack to support the weight of the Advanced RPS chassis when installed into the rack. -
Page 24: Placing Units On Top Of Each Other
2: I HAPTER NSTALLING 6 Connect all cables. Placing Units On Top of Each Other CAUTION: Do not place the Advanced RPS alongside your SuperStack RPS. You may stack up to eight of the allowable units (see Appendix C) in a free-standing stack or, if runners or a tray give extra support, on a rack-mounted Advanced RPS. -
Page 25: Power Supply And Fuses
Refer to the Advanced RPS Type 3 Power Module Installation Guide and Advanced RPS Type 3 ‘Y’ Cable Installation Guide. Details of the permissible combinations of modules and 3Com products are given in Appendix C and the user guide which accompanies the modules. -
Page 26: Standard Dc Cables
2: I HAPTER NSTALLING CAUTION: The Type 3 DC Power Module is for installation by suitably qualified service personnel only. Refer to the Type 3 Power Module Installation Guide. CAUTION: Only use the cables designed for the power module you are installing. -
Page 27: Powering Up The Advanced Rps
Powering Up the Advanced RPS Once the Advanced RPS is in place, you can power up the unit. 1 Connect the AC power cord(s) to the power sockets (mains AC power inlets) at the rear of the RPS. The chassis will always draw power through mains inlet A (labelled Primary Pwr A) in preference to inlet B (labelled Backup Pwr B). -
Page 28: Connecting An Uninterruptible Power System (Ups)
CAUTION: It is important that, if you use a UPS to supply the Advanced RPS, you use only one UPS output to supply the RPS. The 3Com UPS will supply 325 W input power. Hence the maximum output DC power of the Advanced RPS is reduced to about 200 W. -
Page 29: Safety Information
AFETY NFORMATION You must read the following safety information before carrying out any installation or removal of components, or any maintenance procedures on the SuperStack 3 Advanced RPS. WARNING: Warnings contain directions that you must follow for your personal safety. Follow all directions carefully. You must read the following safety information carefully before you install or remove the unit. - Page 30 A: S PPENDIX AFETY determine loading limitations. It is important that the loading limitations are not exceeded. Connect the unit to an earthed power supply to ensure compliance with safety standards. It is essential that the socket outlet is installed near to the unit and is easily accessible.
- Page 31 3Com require that you confirm that your chassis supports the dual phase feature by checking that “3C16071A” or “3C16071B” appears on the serial number label on the base of the chassis, the front panel overlay, and also on the packaging label.
-
Page 32: L'information De Sécurité Importante
A: S PPENDIX AFETY L’information de Sécurité Importante Veuillez lire à fond l'information de la sécurité suivante avant d'installer l’Advanced RPS. ATTENTION: le Power Module de Type 3 doit être installé uniquement par le personnel qualifié. Se réféfer au manuel d'installation du Power Module de Type 3. - Page 33 étiqueté Neutre, branché directement à la Terre (à la Masse). A la requête de 3Com, vous devez confirmer que votre châssis fournit la fonction double phase en vérifiant que le numéro 3C16071A ou 3C16071B est indiqué sur l'étiquette du numéro de série en bas du châssis, sur le panneau avant et également sur...
-
Page 34: Wichtige Sicherheitsinformationen
A: S PPENDIX AFETY Débranchez les conducteurs électriques secteur avant de procéder à une intervention d'entretien courant. Wichtige Sicherheitsinformationen Bitte unbedingt vor dem Einbauen des Advanced RPS Einheit die folgenden Sicherheitsanweisungen durchlesen. WARNUNG: Die Installation des Stromversorgungsmoduls darf ausschließlich von hinreichend ausgebildetem Wartungspersonal durchgeführt werden. -
Page 35: Europe
(Mindestanforderung) sein und die Aufschrift <HAR> oder <BASEC> tragen. Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”). 3Com verlangt von Ihnen die Bestätigung, daß Ihr Chassis die duale Phasenfunktion unterstützt, indem Sie nachprüfen, daß "3C16071A" oder “3C16071B” auf der Seriennummernplakette an der Chassis-Basis, am Frontplatten-Overlay sowie am Verpackungsetikett erscheint. - Page 36 A: S PPENDIX AFETY NFORMATION...
-
Page 37: Technical Specifications
0° to 50°C (32° to 122°F) –10° to +70°C (14° to 158°F) 10 to 95% relative humidity, non-condensing EN60068 to 3Com schedule (Package testing: paras 2.1, 2.2, 2.30, and 2.32. Operational testing: paras 2.1, 2.2, 2.30 and 2.13). IEC 60950, UL 1950, EN60950, CSA 22.2 No. 950... -
Page 38: Power Modules
B: T PPENDIX ECHNICAL Power Modules Electrical Type 1 60 W Power Module Typical Input power: 100 W – Type 1 100 W Power Module Typical Input Power: 167 W Type 2A (100 W) Power Module Typical Input Power: 167 W PECIFICATIONS Maximum power output 12.6 V... -
Page 39: Type 3 (325 W) Power Module
Type 3 (325 W) Power Module CAUTION: The Type 3 DC Power Module is for installation by suitably qualified service personnel only. Refer to the Type 3 Power Module Installation Guide. Typical Input Power: 365 W Physical Dimensions Maximum power output 27 V Total continuous output power: 325 W maximum. - Page 40 B: T PPENDIX ECHNICAL PECIFICATIONS...
-
Page 41: Module Configurations
Table 2. If you are using a pair of modules, connected by a ’Y’ cable in full redundancy mode, these two count as one module. CAUTION: The Advanced RPS chassis (3C16071A and 3C16071B) does not support the Type 2 Power Module (3C16074). You must use a Type 2A Power Module (3C16074A). - Page 42 C: M PPENDIX ODULE Type 2 or Type 2A Power Modules may be used in combinations similar to the Type 1 100 W Power Modules. Table 2 Maximum Number of Advanced RPS Power Modules per Chassis Type 1 60 W Configuration Module (3C16072)
-
Page 43: Full Redundancy Configurations
Full Redundancy Configurations If you want a fully redundant configuration, you can pair power modules (of the same type) in the chassis, provided you use Y-cables of the appropriate type to connect a pair of modules to a single SuperStack unit. The two modules count as one module. This is then subject to the loading limitations and configuration recommendations detailed in Table 2. - Page 44 C: M PPENDIX ODULE SuperStack Products requiring a Type 1 60 W Power Module 3C215A 3C250-T4 3C250A-TX/I *3C7204A *3C7208A 3C8200C 3C8201C 3C8221C 3C8222C 3C8223C 3C8224C 3C8227C 3C8228C 3C8252A 3C8254A 3C8323C 3C8327C 3C8352A 3C8354A 3C8421C 3C8422C 3C8423C 3C8424C 3C8427C 3C8523C 3C8527C *3C16400 *3C16401 *3C16405...
- Page 45 *3C16406 PS Hub 40 24-port (also with a valid combination of 3C1206X Transceiver Modules fitted) *3C16450 PS Hub 50 24-port (also with a valid combination of 3C1206X Transceiver Modules fitted) 3C16665A Hub 10 Fiber (also with 3C16630A or 3C16632 Management Module and 3C1206X Transceiver Module fitted) 3C16670A Hub 10 12-port (also with 3C16630A or 3C16632...
- Page 46 C: M PPENDIX ODULE 3C94103R-CSIX 3C94103R-CSD 3C94103R-CSDI 3C94103R-CSE 3C94117C-XS 3C94133C-XS 3C94101M-SDEK 3C220000A SuperStack Products requiring a Type 1 100 W Power Module 3C16900A 3C16901A *3C16950 *3C16951 *3C16902 3C16940A 3C16941A *3C16942 3C220000A SuperStack Products requiring a Type 2 or Type 2A (100 W) Power Module *3C250C–xx *3C510–SX *3C16610...
-
Page 47: Units Not Supported
*3C16987 *3C16988 *3C39024/36 *3C93011/2 *3C16464 *3C16465 SuperStack Products requiring a Type 3 Power Module *3C17700 *3C17702 Units not supported SuperStack Products NOT supported by the Advanced RPS 3C16910 3C16990 3C81600 3C8930A 3C8960A 3C16010/1/2 3C565047A Switch 3300 SM Switch 3300 MM Switch 3900 Switch 9300 Baseline 10/100 Switch 12-port... -
Page 48: Obsolete Products
C: M PPENDIX ODULE Obsolete Products The following products have been replaced by SuperStack units, but the Advanced RPS will support them. Superseded Products requiring a 60 W Type 1 Power Module LinkBuilder 3C215A 3C250-TX 3C16665 3C16670 3C16671 3C16672 3C510510B 3C510511B NETBuilder Routers 3C8200C... - Page 49 3C8423C NETBuilder Remote Office 423 3C8424C NETBuilder Remote Office 424 3C8427C NETBuilder Remote Office 427 3C8523C NETBuilder Remote Office 523 3C8527C NETBuilder Remote Office 527 LinkSwitch 3C16900 LinkSwitch 1000 24-port (also with 3C1206x or 3C16920/2 modules fitted) 3C16901 LinkSwitch 1000 12-port (also with 3C1206x or 3C16920/2 modules fitted) 3C16940 LinkSwitch 3000 (also with 3C1206x or 3C16920/2...
- Page 50 C: M PPENDIX ODULE 3C32700A 3C32710A 3C32711A 3C220000A ONFIGURATIONS Switch 2700 OC-3 Multimode ATM Switch 2700 DS-3 ATM Switch 2700 OC-3 Singlemode ATM LinkSwitch 2200...
-
Page 51: Troubleshooting
ROUBLESHOOTING If the LEDs on the SuperStack problem refer to Table 3 which contains a list of problems and possible faults. If you have a problem that is not listed here and you cannot solve it, please contact your local technical support representative. Refer to Appendix E. - Page 52 D: T PPENDIX ROUBLESHOOTING...
-
Page 53: Technical Support
For the most recent information, 3Com recommends that you access the 3Com Corporation World Wide Web site. Online Technical Services 3Com offers worldwide product support 24 hours a day, 7 days a week, through the following online systems: World Wide Web site... -
Page 54: 3Com Ftp Site
3Com FTP Site Download drivers, patches, software, and MIBs across the Internet from the 3Com public FTP site. This service is available 24 hours a day, 7 days a week. To connect to the 3Com FTP site, enter the following information into... - Page 55 3Com technical telephone support phone number at the location nearest you. When you contact 3Com for assistance, have the following information ready: Product model name, part number, and serial number A list of system hardware and software, including revision levels...
-
Page 56: Returning Products For Repair
South America North America Returning Products for Repair Before you send a product directly to 3Com for repair, you must first obtain an authorization number. Products sent to 3Com without authorization numbers will be returned to the sender unopened, at the sender’s expense. - Page 57 00800 3111206 0800 831416 0800 995014 900 983125 020 795482 0800 55 3072 0800 966197 1 800 NET 3Com (1 800 638 3266) Enterprise Customers: 1 800 876 3266 Fax Number + 65 543 6348 + 31 30 6029999 1 408 326 7120...
- Page 58 E: T PPENDIX ECHNICAL UPPORT...
- Page 59 NDEX Numerics 3Com Knowledgebase Web Services 53 3Com URL 53 Advanced RPS Chassis dimensions 37 size 37 weight 37 air flow 22, 24 auto-enable feature 18, 27 Cables ’Y’ DC 16 connecting 26 redundancy 16 standard DC 16 configurations full redundancy 19...
- Page 60 Safety Information English 29 French 32 German 34 SNMP 14 stacking units 24 technical support 3Com Knowledgebase Web Services 53 3Com URL 53 network suppliers 54 product repair 56 UPS (Uninterruptible Power System) 14, URL 53 World Wide Web (WWW) 53...
- Page 61 For any third party products listed in the 3Com software product documentation or specifications as being compatible, 3Com will make reasonable efforts to provide compatibility, except where the non-compatibility is caused by a "bug"...
- Page 62 3Com. The repaired or replaced item will be shipped to Customer, at 3Com's expense, not later than thirty (30) days after 3Com receives the defective product, and 3Com will retain risk of loss or damage until the item is delivered to Customer.
- Page 63 IMITATION OF IABILITY TO THE FULL EXTENT ALLOWED BY LAW, 3COM ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF...
- Page 64 EGULATORY OTICES FCC S TATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
