Many sources of information are available to help you identify and resolve issues you may experience:
•
the LEDs on the front panel of the gateway.
•
the graphical User Interface (http://10.0.0.138).
A.3 Front panel LEDs
Note
When the gateway is switched on, the POWER LED on the front panel is green.
item Icon
1- Power
2- Sync
3-
Internet
4- Wi-Fi
5- VOIP
A.4 Diagnostics tool
You can monitor the gateway's activity and status using the several tools.
If none of the above helps you solve the problem, and you are still having trouble connecting to the Internet,
we recommend that you restart your gateway (cf. § A.6) and eventually reset the factory configuration
(cf. § A.7). You will then need to re-configure your gateway as a first-time setup.
eir fibre box User Manual
Text
Solid green: Device is powered on and has booted up
successfully
Power Off: Power off
Blinking red: Device is booting
Solid Red: Device failed to power up properly
Solid green: DSL line is synchronised, or a WAN ETH cable
is connected to the WAN port and the link is active
Blinking slowing: Trying to detect DSL carried
Sync
Blinking fast: Detected DSL carrier and trying to
synchronise
Off: No Broadband connection is plugged in or power is off
Solid green: IP address is received on Data WAN Internet
interface.
Internet
Off: No Data WAN Internet service
Solid green: WiFi is turned on
Off: WiFi is off
Blinking green (slow): WPS is triggered and WPS pairing
Wi-Fi
slot is open
Blinking green (fast): during 2 secs when the pairing is
successful
Solid green: VoIP account is registered
Phone
Off: VOIP service is off
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Spec Colour
Green /
Red
Green
Green
Green
Green
