8 – Pump specifications
Hydraulic fittings
NPT
Standard maximum
Size
N∙m
1/4 in. 34
3/8 in. 47
1/2 in. 61
3/4 in. 75
1 in. 88
1-1/4 in. 108
1-1/2 in. 129
This table shows maximum values. The torque necessary to make a sufficient seal depends on the condition of the pipe
threads and could be much lower than the maximum.

For hydraulic fittings, lubricate the O-rings with hydraulic fluid or O-ring lubricant before assembly.

Hypertherm recommends using thread sealant on all NPT hydraulic fittings. When using thread sealant on a male
tapered pipe thread with a female straight or parallel pipe thread, the maximum value is 50% of the standard maximum.
