38
C
3: S
HAPTER
ETTING
U
M
P FOR
ANAGEMENT
No parity
■
1 stop bit
■
No hardware flow control
■
Refer to the documentation that accompanies the terminal emulation
software for more information.
Viewing IP Information Via the Console Port
You are now ready to view the automatically allocated IP information
using the command line interface.
1 Connect your Switch to the network using an Ethernet cable. As soon as
a network connection is made, the Switch begins the automatic IP
configuration process.
The automatic IP configuration process usually completes within one
minute.
The command line interface login sequence begins as soon as the Switch
detects a connection to its console port.
If the login prompt does not begin immediately, press Return a few times
until it starts.
2 At the login and password prompts, enter admin as your user name and
press Return at the password prompt. If you have logged on correctly, the
top-level menu of the command line interface is displayed, as shown in
the example in Figure 10.
Figure 10 Example Top-level Command Line Interface Menu
Menu options: -------3Com SuperStack 3 Switch 3870 48-port--------
bridge
feature
gettingStarted
logout
physicalInterface
protocol
security
system
trafficManagement
Type ? for help.
-------------------------------- (1)------------------------------
Select menu option:
3 At the Select menu option prompt, enter the protocol ip
interface summary command. At the Select IP interfaces
prompt, enter all. A summary of the automatically allocated IP
information is displayed. Make a note of the network IP address.
- Administer bridge-wide parameters
- Administer system features
- Basic device configuration
- Logout of the Command Line Interface
- Administer physical interfaces
- Administer protocols
- Administer security
- Administer system-level functions
- Administer traffic management
