INSTALLATION

FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
their own expense.

Precautionary Designations

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.

Mounting

The VIP-201A SIP Paging Gateway is designed
for rack, shelf, or wall mounting.
Rack: Attach the brackets to the four holes
closest to the front on each side, then mount the
unit to a 19" rack.
Shelf: Provided with the VIP-201A SIP Paging
Gateway are four rubber stick-on pads. Peel the
pads from their carrier backing and place at the
four corners of the bottom of the unit.
Wall: Using the brackets and wood screws
provided, secure the VIP-201A SIP Paging
Gateway to the wall.
Power Connections
The preferred method of powering a VIP-201A is
via a power over Ethernet switch meeting the
802.3af specification. If the rear panel barrel
connector is used for power, the preferred power
supply is a Valcom VIP-324D. Make all required
signal connections before applying power to the
unit.

Network Connection

The VIP-201A has one RJ-45 network connector
on the front panel.
Use a standard Ethernet patch cable to connect
the VIP-201A to an Ethernet switch. If the
Ethernet switch is 802.3af compliant the VIP-
201A will draw power from it.
Signal Connections
The VIP-201A has signal connections on the rear
panel:
• RCA jack for AUX audio input
• 2 audio outputs
• 4 Pin screw terminal (Audio/CC not used)
• 2 Form C relay connections
AUX Input: Local audio may be input via the
rear panel RCA jack. Nominal input impedance
is 600 Ohms. Connect any compatible audio
source using an RCA patch cable. Audio
supplied through the rear panel RCA jack is
transformer coupled to Audio Out whenever it is
idle. This is typically used for background music.
Audio Out: Two audio output connections are
provided. The terminals labeled "Page" provide a
signal output compatible with Valcom
self-amplified speakers. Up to 40 Valcom
speakers can be connected to the Page output.
The terminals labeled "AUX" provide a signal
output compatible with most amplifiers and
should be used where a transformer-coupled
output is desired.
DIP Switch: The four-pole DIP switch controls a
supervision signal on the "Page" audio output
line. For systems where supervision is used,
setting DIP switches 1 & 2 to ON enables
supervision on the Page audio output
connections. Where supervision is not used, set
DIP switches 1 & 2 to OFF. Switches 3 & 4 are
not used.
Relay Channels: Access to the two Form C
relays is provided via a six-pin screw terminal
block. The relays are labeled K1 and K2. Each
relay is brought out on three terminals. The
common contact (COM) is the middle terminal
with the normally closed (N.C.) contact on the
right and the normally open (N.O.) contact on the
left. Relay contacts are rated for 1A @ 24VDC.
