Installation
14 AWG
Volts HP
(2mm²)
110
115 1/2
(33)
438
1/2
(134)
365
230 3/4
(111)
304
1
(93)
Table 2 - Power Supply Wire (Cable) Length in Feet (m)
Single Phase, 2 Wire Cable, 60 Hz (Copper Wire Size - Service to motor)

Installation Wiring Diagrams

Risk of electric shock . Can shock,
burn or kill. Ground control box, all metal
plumbing, and motor frame with copper wire in
compliance with local codes. Use a ground wire
at least as large in gauge as the wires supplying
power to the motor.
Single Phase, 2 Wire
2-wire pumps have two power supply wires
(Black/Black) and one ground wire (Green).
Control box is not required. See Figure 1 for
correct hook-up information for 2-Wire motors.
Figure 1 - Single phase, 2-wire connections. This
is correct connection information for 115 and
230 volt 2-wire motors only.
12 AWG 10 AWG 8 AWG
(3 .3mm²) (5 .3mm²) (8 .4mm²)
174 278 440
(53) (85) (134)
697 1112 1761
(213) (339) (537)
581 927 1468
(177) (282) (447)
484 772 1223
(148) (235) (373)
6 AWG 4 AWG
(13 .3mm²) (21 .1mm²) (26 .7mm²)
685 1092
(209) (333)
2740 4369
(835) (1332)
2284 3641
(696) (1110)
1903 3034
(580) (925)
Installation must meet United States National
Electrical Code, Canadian Electrical Code,
and local codes for all wiring (as applicable).
If main overload trips, look for:
1. Shorted capacitor
2. Voltage problems
3. Overloaded or locked pump.
3 AWG 2 AWG 1 AWG
(33 .6mm²) (42 .4mm²)
1373 1734
(419) (529)
5492 6936
(1674) (2114) (2663)
4577 5780
(1395) (1762) (2219)
3814 4817
(1163) (1468) (1849)
4
0 AWG
(53 .5mm²)
2184 2757
(666) (840)
8738 11029
(3362)
7281 9191
(2801)
6068 7659
(2335)
