  • Page 1 10-15 / 34-40 190.2 190.4 XL 73502-V2-13/01/2014...
  • Page 2 PEARL 190.2 PEARL 190.4 XL NO GAS...
  • Page 3 PEARL 190.2 PEARL 190.4 XL PEARL 190.2 PEARL 190.4 XL...
  • Page 4 The device must be installed so that the mains socket is accessible. Do not use an extension cable with a diameter of less than 1.5mm². PEARL 190.2/PEARL 190.4 XL is delivered with a 16amp plug (TYPE CEE7-7), and the machine features a highly efficient PFC and Flexible Voltage technology.
  • Page 5 PEARL 190.2 PEARL 190.4 XL SETTINgS PANEL (FIg V) • SETUP button + Button (4) : to select the SYNERGIC or MANUAL mode • SETUP button + Button (5) : switching to material settings (see table page 7) • SETUP button + Button (4) : to select...
  • Page 6 (3) to the maximum. - PEARL 190.2 : the adapter (1) is to be used only for 200mm wire reel assembly • Adjust the reel brake (2) to avoid reel movement tangling the wire when welding stops. Be careful not to tighten too much.

  • Page 7: Maintenance / Advice

    (DANGER High Voltage and Currents). • GYS recommends removing the steel cover 2 or 3 times a year to remove any excess dust. Take this opportunity to have the electrical connections checked by a qualified person with an insulated tool.
  • Page 8 PEARL 190.2 PEARL 190.4 XL SAFETY Arc welding can be dangerous and can cause serious and even fatal injuries. Protect yourself and others. Ensure the following safety precautions are taken: Arc radiation Protect yourself with a helmet fitted with filters in compliance with EN169 or EN 379.

  • Page 9: Troubleshooting

    PEARL 190.2 PEARL 190.4 XL TROUBLESHOOTINg SYMPTOMS POSSIBLE CAUSES REMEDIES The welding Debris is blocking up the opening. "Clean out the contact batch or change it and replace wire speed is not the anti-adherence product. constant. Ref.041806." The wire skids in the rollers.
  • Page 10 • La garantie ne couvre pas l’usure normale des pièces (Ex. : câbles, pinces, etc.). En cas de panne, retournez l’appareil à la société GYS (port dû refusé), en y joignant : • Le présent certificat de garantie validé par le vendeur •...

  • Page 11: Декларация О Соответствии

    CE Kennzeichnung: 2013. DECLARACIóN DE CONFORMIDAD : Gys certifica que los aparatos de soldadura PEARL 190.2 y PEARL 190.4 XL son fabricados en conformidad con las directivas baja tensión 2006/95/CE del 12/12/2006, y las directivas compatibilidad electromecánica 2004/108/CE del 15/12/2004. Esta conformidad está establecida por el respeto a las normas EN60974-1 de 2005, EN 50445 de 2008, EN 60974-10 de 2007.
  • Page 12 PEARL 190.2 PEARL 190.4 XL PIÈCES DE RECHANGE / SPARE PARTS / ERSATZTEILE/ PIEZAS DE RECAMBIO/ ЗАПЧАСТИ PEARL PEARL N° 190.2 190.4 XL Motodévidoir (sans galet) / Wire feeder (without roller) / Drahtvors- tub (ohne Drahtrollen) / Devanadera (sin rodillos) / Подающий...
  • Page 13 PEARL 190.2 PEARL 190.4 XL SCHÉMA ÉLECTRIQUE / CIRCUIT DIAGRAM /SCHALTPLAN/ DIAGRAMA ELECTRICO/ЭЛЕКТРИЧЕСКАЯ СХЕМА...
  • Page 14 PEARL 190.2 PEARL 190.4 XL ICONES / SYMBOLS / ZEICHENERKLÄRUNg Ampères - Amps - Ampere - Amperios - Ампер Volt - Volt - Volt - Voltios - Вольт Hertz - Hertz - Hertz - Hertz - Герц - Soudage MIG/MAG (MIG: Metal Inert Gas / MAG: Metal Active Gas) - MIG/MAG Welding (MIG: Metal Inert Gas / MAG: Metal Active Gas) - MIG/MAG Schweißen (MIG: Metal Inert Gas/ MAG: Metal Active Gas)
  • Page 15 PEARL 190.2 PEARL 190.4 XL ICONES / SYMBOLS / ZEICHENERKLÄRUNg - U2: Tensions conventionnelles en charges correspondantes. - U2: conventional voltages in corresponding load. U2 ...% - U2: entsprechende Arbeitsspannung. - U2: Tensiones convencionales en carga. - U2: соответствующие сварочные напряжения*.
  • Page 16 PEARL 190.2 PEARL 190.4 XL ACCESSOIRES/ACCESSORIES / ZUBEHÖR / ACCESORIOS / АКСЕССУАРЫ PEARL 190.2 ø 100 ø 200 0.6 - 1.0 086593 (ø0.6) 086128 (ø0.8) Acier/Steel/Stahl 086609 (ø0.8) 086135 (ø1.0) 041592 041905 (ø0.6) 042339 (ø0.6/0.8) 041424 041875 (ø0.6/0.8 - 3m) 041912 (ø0.8)

This manual is also suitable for:

Pearl 190.4 xl
