For a good result you can adjust further values
from the menu „Color Adjustment". Depending
on the exact model of your camera, certain
menu points in the software might be inactive if
not supported by the camera hardware.
TIP:
To use the MikrOkular long-
i
term we recommend it always
be connected to the same USB
port.
11. Using the MicrOcular
11.1. Preparation
1. Slide a specimen under your microscope and
focus on it.
2. Remove the eyepiece and Barlow lens from
the eyepiece support and the dust cap from
your MikrOkular and install same in the
eyepiece supports instead of the Barlow
lens.
3. Start your PC if you haven't yet and connect
your MikrOkular to the USB port of your
computer.

Care and maintenance

Separate the device from the power supply
before cleaning (remove batteries)!
20
Only use a dry cloth to clean the exterior of the
device.
NOTE:
Do not use any cleaning
fluid to avoid damaging the
electronics.
Clean the lenses (eyepiece and/or lens) with a
soft and lint-free cloth only (e.g. microfibre).
NOTE:
Do not apply excess pressure
to the cloth so as to avoid
scratching the lenses.
To remove more stubborn dirt, moisten the
cleaning cloth with an eyeglass-cleaning
solution and wipe the lenses gently.
Protect the device from dust and moisture!
After use - in particular in situations of high
humidity - let the device acclimatize for a short
period of time, so that the residual moisture
can dissipate.

Troubleshooting

Error Solution
No picture visible switch light on
put condenser lens
in place
adjust focus

Specifications

System requirements (PC Ocular)
PC with dual core processor (2.8 GHz minimum)
or higher; Operating system Windows 7/8/10;
4 GB RAM minimum; 2 GB free HDD space
minimum; free USB 2.0 port; CD/DVD drive.
Magnification table
Eyep. Object. Magn.
5x 4x 20x
5x 10x 50x
5x 40x 200x
16x 4x 64x
16x 10x 160x
16x 40x 640x
with Barlow l.
40x
100x
400x
128x
320x
1280x
