  • Page 1 Brukerveiledning Installation manual Installationsanvisning Asennusohje Montageanleitung Manuel d’installation Monaco II Low Base + Bench Art.no: FP-MON02-100, FP-MON02-300, FP-MON02-400, FP-MON02-500 Last updated: 09.08.2019 Test Report No: RRF 40 16 4231...

  • Page 2: Important Safety Precautions

    2. Before use, please carefully read the user manual client that these regulations are complied with in and follow the instructions. Nordpeis AS is not responsible for incorrect installation. never be reduced or partially obstructed. This may lead to overheating, which again can cause house...
  • Page 3 The air gap must not under any circumstances be Assembly instructions: - Monaco II Low Base (FIG 1-16); - Monaco II Low Base + Bench - (FIG 1-10) + FIG (17-22); - Monaco II Low Base + Wood Shelf - (FIG 1-12c) + FIG (23-29).
  • Page 4 Monaco II Low base / Q-34 UL = mm FIG 1 Monaco II Low base + bench / Q-34 UL = mm FIG 1 a...
  • Page 5 Monaco II Low base + wood shelf / Q-34 UL = mm FIG 1 b Monaco II Low base / Q-34 UL = Chimney / AIR mm FIG 1 c...
  • Page 6 Monaco II Low base_Q-34 UL FIG 2 =Firewall/ Hitzenschutzwand / Mur parfeu / Parete non combustibile / Palomuuri =Combustible material / Brennbarem Material / Matières combustibles/ Parete combustibile / Tulenarka materiaali 1200 mm 1200 mm...
  • Page 7 NO: Viktig! For å sikre nødvendig konveksjonsluft, kan kun originale gulv plater fra Nordpeis benyttes. GB: Attention! In order to secure required convection opening, only original Nordpeis Floor plates should be used. SE: Obs! För att säkerställa erforderlig konvektionsöppning ska endast Nordpeis originalgolvplattor användas.
  • Page 8 Monaco II Low base_Q-34 UL FIG 3 a Air / Luft / Ilma Monaco II Low Base_Q-34 UL FIG 4 10 mm...
  • Page 9 Monaco II Low Base_Q-34 UL FIG 4 a 180 0 Monaco II Low Base_Q-34 UL FIG 4 b 10 mm...
  • Page 10 Monaco II Low Base_Q-34 UL FIG 4 c Monaco II Low Base_Q-34 UL FIG 5 22-MON02-02L 22-MON02-02R 21-50001-018 x4 21-30004-016 x4 10 mm...
  • Page 11 Monaco II Low Base_Q-34 UL FIG 6 22-MON02-060 x4 21-30011-408 x8 TORX Monaco II Low base_Q-34 UL FIG 7 NO: Om ildstedet skal monteres med tilslutning av pipe bak og tilluftskanal, lag hull etter perforeringen i platen. Betongring monteres mellom platen og veggen, GB: If you utilize either rear chimney connection and external air duct make a hole cutting out perforation and place a concrete ring between the plate and adja- cent wall - see FIG 7b.
  • Page 12 Monaco II Low base_Q-34 UL FIG 7 a Monaco II Low base _Q-34 UL FIG 8 21-30004-016 x2 21-50001-018 x4 21-00000-006 x2 M A X 10 mm...
  • Page 13 Monaco II Low base _Q-34 UL FIG 8 a 21-30004-016 x2 21-50001-018 x4 21-00000-006 x2 M A X 10 mm Monaco II Low base_Q-34 UL FIG 9 CO-MON00-01A...
  • Page 14 Monaco II Low base_Q-34 UL FIG 9 a 13 mm Monaco II Low base_Q-34 UL FIG 10 21-50001-018 x2 21-30004-016 x2 M A X 10 mm...
  • Page 15 FIG 11 FIG 16 FIG 17 FIG 22 Monaco II Low base_Q-34 UL FIG 11 22-MON02-040 x2 21-30004-016 x4 21-50001-018 x4 10 mm...
  • Page 16 Monaco II Low base_Q-34 UL FIG 12 CO-MON02-S40 x1 21-50001-018 x2 21-30004-035 x2 CO-MON02-010 x1 Monaco II Low base_Q-34 UL FIG 12 a 21-50001-018 x4 21-30004-016 x4 22-MON02-050 x2 10 mm...
  • Page 17 Monaco II Low base_Q-34 UL FIG 12 b Monaco II Low base_Q-34 UL FIG 12 c 10 mm...
  • Page 18 FIG 23 FIG 29 Monaco II Low base_Q-34 UL FIG 13 4 mm CO-MON02-020 x2 22-MON02-130 x2 21-30001-614 x4...
  • Page 19 Monaco II Low base_Q-34 UL FIG 13 a 4 mm 21-30001-614 x4 Monaco II Low base_Q-34 UL FIG 14 CO-MON02-S40 x1 CO-MON02-030 x1 21-50001-018 x2 21-30004-035 x2...
  • Page 20 Monaco II Low base_Q-34 UL FIG 14 a 22-MON02-03R 22-MON02-03L 21-50001-018 x6 21-30004-016 x6 CO-MON02-030 10 mm Monaco II Low base_Q-34 UL FIG 14 b 150 mm...
  • Page 21 Monaco II Low base_Q-34 UL FIG 14 c Monaco II Low base_Q-34 UL FIG 14 d AF-MON02-010 x2 21-50001-018 x4 21-00000-006 x4 10 mm...
  • Page 22 Monaco II Low base_Q-34 UL FIG 15 22-MON00-030 x2 22-MON00-040 x1 Monaco II Low base_Q-34 UL FIG 15 a 22-MON00-030 x2 22-MON00-040 x1...
  • Page 23 Nordpeis benyttes. GB: Attention! In order to secure required convection opening, only original Nordpeis Floor plates should be used. SE: Obs! För att säkerställa erforderlig konvektionsöppning ska endast Nordpeis originalgolvplattor användas. FI: Huom! Käytä vain alkuperäisiä Nordpeis-lattialevyjä vaaditun konvektioaukon (ilmankierron) varmistamiseksi.
  • Page 24 Monaco II Low base + bench_Q-34UL - Assembling Monaco II Low base + bench_Q-34UL FIG 17 CO-MON00-13L x1 22-MON00-110 x2 21-30001-666 x4 CO-MON00-140 x1 4 mm CO-MON00-13R x1...
  • Page 25 Monaco II Low base + bench_Q-34UL FIG 17 a Monaco II Low base + bench_Q-34UL FIG 18 CO-MON02-S10 x1 21-50001-018 x2 21-30004-040 x2 CO-MON02-060 x1...
  • Page 26 Monaco II Low base + bench_Q-34UL FIG 18 a Monaco II Low base + bench_Q-34UL FIG 19 4 mm CO-MON02-020 x2 22-MON02-130 x2 21-30001-614 x4...
  • Page 27 Monaco II Low base + bench_Q-34UL FIG 19 a 4 mm 21-30001-614 x4 Monaco II Low base + bench_Q-34UL FIG 19 b...
  • Page 28 Monaco II Low base + bench_Q-34UL FIG 19 c Monaco II Low base + bench_Q-34UL FIG 20...
  • Page 29 Monaco II Low base + bench_Q-34UL FIG 20 a 10 mm FIG 13a-15a...
  • Page 30 Monaco II Low base + bench_Q-34UL FIG 21 Monaco II Low base + bench_Q-34UL FIG 22 FIG Z...
  • Page 31 SE: Varning! Håll luftintag, som tillför förbränningsluft, fria från blockeringar. FI: Varoitus! Pidä huoli että kiertoilma-aukot eivät tukkeudu missään tapauksessa. min 2,4 cm! DE: Warnung! Lufteinlässe, durch die FR: Avertissement ! Ne pas obstruer les Monaco II Low base + wood shelf_Q-34 UL - Assembling...
  • Page 32 Monaco II Low Base + wood shelf FIG 23 CO-MON00-220 x2 Monaco II Low Base + wood shelf FIG 24 a...
  • Page 33 Monaco II Low Base + wood shelf FIG 24 b Monaco II Low Base + wood shelf FIG 25 MO-MON00-18H x1...
  • Page 34 Monaco II Low Base + wood shelf FIG 26 17 mm 23-00054-000 Monaco II Low Base + wood shelf FIG 27 a 4 mm CO-MON02-020 CO-MON02-08R 22-MON02-130 x2 21-30001-614 x8...
  • Page 35 Monaco II Low Base + wood shelf FIG 27 b 4 mm CO-MON02-08R CO-MON02-08L CO-MON02-020 22-MON02-130 x2 21-30001-614 x8 Monaco II Low Base + wood shelf FIG 27 c 90 0...
  • Page 36 Monaco II Low Base + wood shelf FIG 27 d Monaco II Low base + wood shelf_Q-34 UL FIG 28 FIG 14-15a...
  • Page 37 Monaco II Low base + wood shelf_Q-34 UL FIG 29 FIG Z...
  • Page 38 Nordpeis AS Gjellebekkstubben 11 3420 Lierskogen, Norway MonacoII-CPR-2019/04/26 EN 13240:2001 / A2:2004 / AC:2007 Monaco II Low / High Heating of living accomodation / Kamin zum Heizen mit festen Brennstoffen Fire safety: Feuersicherheit : Reaction to fire: Brandverhalten: Distance to combustible:...
  • Page 39 Nordpeis AS, Gjellebekkstubben 11, N-3420 LIERSKOGEN, Norway www.nordpeis.no...
