4.2 WHAT ARE PRESETS AND HOW TO USE THEM
The most famous electromechanic organs were also equipped with drawbars combinations through which
factory Presets could be used, without the need to manually change the position of the drawbars. These
combinations, which back then could not be modified by the user, were called Presets and could be accessed
through the first octave of the keyboard, characterised by inverted key colours and therefore called Black
Octave.
Legend Legend Classic
and
recalled through the keys from C# to A.
Legend Live
has two Preset for each manual. To recall them, press the buttons [UPPER PRESETS 1] and
[UPPER PRESETS 2] for the upper manual, or [LOWER PRESETS 1] and [LOWER PRESETS 2] for the lower
manual.
As in the original organs, the pedalboard has no Preset.
EDITING AND SAVING PRESETS
Legend
To edit and store a
1. Select the Set A of the manual whose Preset you wish to edit, through the Black Octave of the
corresponding manual.
2. Configure the Preset to your liking by adjusting the drawbars of the Set A corresponding to that manual.
3. Press and hold the [TRANSPOSE SELECT] button, then simultaneously press the C key on the Black
Octave. The leds start to blink, indicating that the instrument is ready to save a Preset.
4. While still holding [TRANSPOSE SELECT], press the Black Octave key corresponding to the Preset you
want to edit and save.
5. Release [TRANSPOSE SELECT].
Legend Live
To edit and save
1. Press the [DRAWBARS SET A] button of the manual whose Preset you wish to edit.
2. Configure the preset to your liking by adjusting the drawbars of the Set A corresponding to the manual.
3. Press and hold the [TRANSPOSE SELECT] button, then simultaneously press the [DRAWBARS SET A]
button. The leds start to blink, indicating that the instrument is ready to save a Preset.
4. While still holding down [TRANSPOSE SELECT], press the button [UPPER PRESETS] or [LOWER
PRESETS] corresponding to the Preset you want to edit and save.
5. Release [TRANSPOSE SELECT].
NB
Keep in mind that, as in the original tonewhells organs, in the Presets:
it is possible to save the state of the drawbars of Set A only,
-
the state of the percussion and Vibrato/Chorus controls cannot be saved.
-
4.3 PERCUSSION
The percussion, typical feature of electromechanical organs, provides a replication of a harmonic that is added
to those set through drawbars, with a rapid attack and an exponential decay. On the original instrument,
percussions are generated only when the drawbar Set B is selected, and the sound generated by the drawbar
1' was disabled when percussion was active:
features.
LEGEND and LEGEND CLASSIC
have a Black Octave for each manual and includes 9 Presets, that can be
Legend Classic
and Preset, follow these steps:
Presets, follow these steps:
Legend
EN - 18
/ Legend Classic / Legend Live
LEGEND LIVE
also has these
