www.somfy.com
YSLO FLEX RTS 1P
Installation guide (1 panel)
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YSLO FLEX RTS 1P and is the answer not in the manual?

Questions and answers

Related Manuals for SOMFY YSLO FLEX RTS 1P

Summary of Contents for SOMFY YSLO FLEX RTS 1P

  • Page 1 YSLO FLEX RTS 1P Installation guide (1 panel)
  • Page 2 Insatallation guide (1panel) page 3 Caution! Note...
  • Page 3 Yslo Flex RTS 1P Copyright © 2012 - 2014 Somfy SAS. All rights reserved.
  • Page 4 Yslo Flex RTS 1P TRANSLATED INSTRUCTIONS These instructions apply to all YSLO FLEX RTS 1P drive, the different versions of which are available in the current catalogue. Field of application MVA drive are designed to drive all types of swinging shutters.

  • Page 5: Table Of Contents

    Yslo Flex RTS 1P motor is designed to motorise all types of swing shutters. Yslo Flex RTS 1P is equipped with a battery that allows it to function autonomously in the event of a power outage (20 operations). In this case, Yslo Flex RTS 1P beeps during the movements for your information.

  • Page 6: General Information

    Yslo Flex RTS 1P motor is designed to motorise all types of swing shutters. Yslo Flex RTS 1P is equipped with a battery that allows it to function autonomously in the event of a power outage (20 operations). In this case, Yslo Flex RTS 1P beeps during the movements for your information.

  • Page 7: Contents

    Smoove O/C RTS control point x 1 + faceplate x 1 Pop rivets x 4, for PVC or Aluminium shutters Stoppers x 2 M10 screws x 2 + Screw covers x 2 + Washers x 2 Rubber seal x 1 Copyright © 2012 - 2014 Somfy SAS. All rights reserved.
  • Page 8 Yslo Flex RTS 1P Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 9: Safety

    Any use outside the sphere of application defined by Somfy is prohibited. This will invalidate the warranty and release Somfy from all liability, as will any failure to comply with the instructions given herein. Never begin installing before checking the compatibility of this product with the associated devices and accessories.

  • Page 10: Installing Yslo Flex Rts 1P

    You can watch the installation video on the website at www.somfypro.fr. 1. Preparing the shutter Yslo Flex RTS 1P must be installed in a location that is sheltered from inclement weather. Yslo Flex RTS 1P is designed only for lintel installation.

  • Page 11: Positioning Yslo Flex Rts 1P

    Yslo Flex RTS 1P Before installing Yslo Flex RTS 1P, the swing shutter must be capable of being opened or closed without difficulty and the lintel must be level in width and depth. 2. Positioning Yslo Flex RTS 1P 1) Close the shutter...

  • Page 12: Choosing The Cable Exit

    The cable guide x must be used to guarantee the electrical safety and integrity of the cable. The power cable must not be cut between the red label and Yslo Flex RTS 1P. Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 13: Fixing Yslo Flex Rts 1P

    Somfy recommends that you use screws with a diameter of at least six millimetres. The choice of the fixing method depends on the nature of the support, and therefore, it will be under your sole responsibility. Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 14: Lintel More Than 690 Mm Wide

    3) Pull the rails out as far as possible while keeping at least 50 mm of the rails engaged inside the electromechanical module. Copyright © 2012 - 2014 Somfy SAS. All rights reserved.
  • Page 15 Somfy recommends that you use screws with a diameter of at least six millimetres. The choice of the fixing method depends on the nature of the support, and therefore, it will be under your sole Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 16: Wiring

    2) Connect the red wire of the battery to the (+) terminal of the battery on the control board 3) Connect the black wire of the PCB to the (-) terminal of the battery: Yslo Flex RTS 1P will begin to beep.

  • Page 17: Commissioning And Saving The Rts Control Point

    Battery operation is not possible for the first 20 operations. You must switch on the mains supply before any operation. 1) Press and hold the button no. 4 on the Yslo Flex RTS 1P board until it beeps. 2) Take the RTS control point The shaft of the panel makes a rotation.

  • Page 18: Installing Stoppers

    High position Yslo Flex RTS 1P is equipped with obstacle detection and stops against the stoppers. 10.2. Fixing the stop on the side • Fix the breakable stop on the wall or on the panel and then insert the buffer.

  • Page 19: Clipping On The Housings

    11.2. Lintel less than 690 mm wide If the lintel is less than 690 mm wide: 1) Clip on the symmetric housing a 2) Clip on the trim housing b Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 20: Lintel More Than 690 Mm Wide

    2) Clip on the trim housing covering the additional housing. 13. Fixing the arms and sliders 13.1. Cutting the sliders. 1) Close the shutters manually 2) Measure the width of the internal panels with shutters closed Internal Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 21: Installing The Arm

    Installation with batten: using a spirit level, you must position the slider horizontally such that it touches the outer edge (the one opposite the hinges) of the panel. The end pieces of the slider j must not protrude Copyright © 2012 - 2014 Somfy SAS. All rights reserved.

  • Page 22: Checking And Resetting The Panel

    Aluminium shutter Wooden shutter Resin shutter Max level Yslo Flex RTS 1P is factory set to level 2. To modify it, follow the steps below: 1) Place the panel in half-open position. 2) Briefly press the buttons on the RTS control...

  • Page 23: Use

    When saving (my) favourite position, Yslo Flex RTS 1P closes the shutter completely and then returns to the saved position. During the movement, Yslo Flex RTS 1P beeps. The product cannot be stopped with a remote control. However, stoppage due to an obstacle remains active during the movement.

  • Page 24: Signalling Movement

    Yslo Flex RTS 1P 17.4. Signalling movement Yslo Flex RTS 1P has a buzzer to warn the user: Somfy recommends that you activate this function to signal the movement of the swing shutter (e.g. shutter on the ground floor and presence of children) and prevent accident risks.

  • Page 25: Maintenance Operation Requiring The Housing To Be Unclipped

    Restoring the original configuration deletes all the control points as well as the saved sensors and favourite position, and the buzzer is deactivated. • Press and hold the button no. 4 on the Yslo Flex RTS 1P board: - The panel makes a first back-and-forth movement with a beep and then a second back-and-forth ≈...
  • Page 26 Yslo Flex 1 RTS NOTES Copyright © 2012 - 2014 Somfy SAS. All rights reserved.
  • Page 27 Yslo Flex 1 RTS NOTES Copyright © 2012 - 2014 Somfy SAS. All rights reserved.
  • Page 28 Somfy SAS 50 avenue du Nouveau Monde F - 74300 CLUSES www.somfy.com...
