- Page 1 Drying Cabinet Installation and Operating Manual Model: TS-5121...
-
Page 2: Table Of Contents
THIS USER MANUAL The contents of this user manual describes the functions of NOTE. Keep this user the TS-5121 drying cabinet and how it should be used. It also manual so it is always includes instructions for installation and maintenance. -
Page 3: Advice On Safe Operation
ADVICE ON SAFE OPERATION This advice on safe operation has been compiled so that you can avoid incorrect use and unnecessary risks of accidents, and should be read before the drying cabinet is installed and used. CAUTION: This equipment is only intended to be used to dry textiles washed in water. WARNING ·... -
Page 4: Installation
INSTALLATION UNPACKING INSTALLATION The dryer is only designed for operation Check for external signs of damage to the packaging. This indicate that indoors in a dry environment at a temperature consignment has suffered damage in transit. Any above freezing point. damage should be immediately recorded on the delivery note and reported to your dealer within 3 days. - Page 5 INSTALLATION INSTALLATION WHERE ACCESS SPACE IS LIMITED The upper section of the cabinet can be removed to reduce the overall height by 207mm. 1.Remove two T20 screws from the under edge of the fascia panel located through the square holes, then slide the panel upwards. Loosen the four T20 screws securing the door switch bracket and slide it backwards.
- Page 6 INSTALLATION EXHAUST CONNECTION The exhaust ducting should not be connected into an existing chimney, boiler flue or tumble dryer system. The dryer must be connected directly to an exhaust ducting system that terminates on the outside of the building. This could be through the roof or on an external wall.
- Page 7 INSTALLATION ELECTRICAL CONNECTIONS NOTE: The cabinet is not supplied with a power supply The power supply cable to the cabinet connecting to cable. a junction box above the cabinet is preferred, with the switch isolator located to the side of the cabinet for ease of access.
-
Page 8: Operating Instructions
Model TS-5121 level of dryness. An automatic cool down period of approximately 8 minutes is built The cabinet is fitted with a stainless steel hanging rail into each cycle. -
Page 9: Maintenance Insturction
MAINTENANCE INSTRUCTIONS CLEANING High pressure water jet cleaning should not used on this cabinet. The use of bleach, caustic solutions and abrasive materials is not recommended. The cabinet should be cleaned (inside and out) with a damp cloth using a mild detergent solution. Dust will collect on top of the cabinet therefore it should be cleaned at least once a year or more frequently depending on the application and location of the unit. -
Page 10: Dimensions
DIMENSIONS Notes: Minimum clearance required for access with the cabinet removed from pallet: Width: 610mm Height: 1838mm Key to dimensions Maximum levelling adjustment: Plus 15mm Minimum clearance required in front of the cabinet with the hanging rail fully extended: 820mm Doors open to 180 degrees and extend 430mm from the end panels. - Page 11 Installation and Operating Manual Page 11...
- Page 12 EQUIPMENT LIMITED Unit 3, Bourne End Mills Upper Bourne End Lane Hemel Hempstead Herts. HP1 2UJ Tel: 01442 872323 info@peko.co.uk www.pekodryingcabinets.co.uk...
