- Page 1 Drying Cabinet Installation and Operating Manual Model:- ETS-1500...
-
Page 2: Table Of Contents
Peko Equipment Limited and maintenance. Peko House Northbridge Road Berkhamsted PEKO Equipment Limited reserve the right to make Herts. HP4 1GE improvements and/or changes to the cabinet and to the contents of this manual: tel: 01442 872323 Origination: 01/2008... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT These instructions and warnings have been provided to help avoid misuse and unnecessary risks and should be read before the cabinet is installed and used. NOTE: Keep this manual in a safe place so that it is always available for future use. WARNING To reduce the risk of fire, electric shock, or ... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS CONTENTS UNPACKING WARNING: The cabinet should be The drying cabinet is supplied complete handled and transported with care. The together with a user manual and fixing kit. unit is top heavy with the risk of tipping over when positioned on its wooden pallet. Remove all packaging material. - Page 5 INSTALLATION INSTRUCTIONS (cont.) REVERSING THE DOOR HINGE SIDE The door is supplied as standard with the hinges to the right hand side. Follow the instructions below to change to left hand side hinge . Place the packaging material on the floor for protection then lay the cabinet down with the door uppermost.
- Page 6 INSTALLATION INSTRUCTIONS (cont.) LOCATING AND FIXING THE CABINET The appliance should not be located in a position such that any doorways or safety exits are impeded with the cabinet door open and the hanging rails extended. The drying cabinet is only designed for operation indoors in a dry environment at a temperature above freezing point.
-
Page 7: Exhaust Connection
INSTALLATION INSTRUCTIONS (cont.) EXHAUST CONNECTION The exhaust ducting for the cabinet can be directed through the top panel or through the left or right hand side panels. Decide which option best suits the installation and if it is to go through a side panel then the partially stamped blanking plate should be removed and the spigot attatched The exhaust ducting should not be connected The cabinet can be connected to an exhaust... -
Page 8: Electrical Connections
INSTALLATION INSTRUCTIONS (cont.) ELECTRICAL CONNECTIONS The cabinet is supplied ready for connection to the power supply with a UK style three pin plug complete with a 10 A fuse. The power supply rated at 220- 240volt, 50-60 Hz. The power cable is approx. 1.8m in length. The plug (and socket outlet) should be in an accessible position for ease of removal. -
Page 9: Operating Instructions
WARNING To reduce the risk of fire, electric shock, or injury to the person, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Model ETS-1500 LOADING THE CABINET The cabinet contains of three Do not lay items flat on the up- sets of hangers each with 10 per hanging rail section. - Page 10 OPERATING INSTRUCTIONS OPERATING CONTROL PANEL The cabinet is designed with two control switches for ease of use. The left hand switch controls heat settings. The ‘0’ position circulates ambient temperature air only. Rotating the switch position in a clock- wise movement increases the heat input up to a maximum 1.5 kW. The optimum setting is with the control set to the start of the double line sector on the scale for lower energy consumption.
- Page 11 OPERATING INSTRUCTIONS (cont.) SETTING THE CONTROLS Always follow the washing instructions as shown on the care labels. Set the temperature and the time to suit the most delicate articles to be dried. Remove garments from the cabinet as they become dry.
-
Page 12: Troubleshooting And Service
TROUBLESHOOTING AND SERVICE PROBLEM The fan does not operate and the cabinet not heating:- Check that the cabinet is connected to the power supply and that the fuses are intact. In the event of further problems please contact your dealer. WARNING Isolate the electrical supply and remove the plug and power cord before withdrawing the service control unit. -
Page 13: Technical Data
TECHNICAL DATA MANUFACTURING APPROVALS Class IP 24 (See data plate for details) Independently tested and CE marked Capacity: 4kg (approx. wet weight) general laundry textiles. Electrical supply: 230v, 50Hz. a.c. Motor: 35W. Heating element: 1500W. Overheat cut-out: Yes. Timer: 0 - 4 Hours. Dimensions: Height. - Page 14 Blank Page Page 14...
