Midea FDB Series Service Manual page 23

4）dismantle the air duct cover of refrigerator
room.
Air duct components in freezing chamber
1） Use cross screwdriver to rotate
anticlockwise, for remove the 4 pcs screws;
2） Dismantle the air duct cover outwards;
3） pull out the fan motor and temperature sensor
plug-in terminal at the upper right corner.
Fan motor
1） Make air duct aluminum foil be away from the
back cover of air duct, Use cross screwdriver to
rotate anticlockwise, for remove the 1 pcs
screw;
2)Use slotted screwdriver to dismantle the clips of
air duct cover;
