3) Continue to pull drawer outwards so as to
separate the metal guide rail;
4)Place the upper freezer drawer on ground as
the way shown in the right picture;
5） )Separate the metal connection lever by pull the
guide rail to the opposite direction;
6）Push the gear slantingly as shown in right
picture, and separate the gear from the guide rail.

8.2 Parts inside the refrigerator

Shelves
1) Hold the front edge of glass shelf by uplift by
certain angle;
2) Uplift the glass shelf ,and separate it from the
shelf;
3）Take out the shelf horizontally.
