6. Internal view and dimension

6.1 Main parts and their names

Refrigerator chamber

6.2 External dimension

Description
Height to Top of Case
Width
Depth
Depth (135deg. with Door Open)
Width (door open 135 deg.)
Service Manual_2018-V1.0
Freezer chamber
Code
A
B
C
D
E
15
Size (mm) Size (in)
1775
910 35.8
737 29.0
993 39.1
1593 62.7
70
