The table below describes possible states for each of the
LED color indicators.
Color
State
Yellow
Solid
Red
Blinking
Red
Solid
Green
Solid
Green
Blinking
Blue
Blinking
Blue
Solid
Purple
Solid
Purple
Blinking
White
Solid/
Blinking
Wi-Fi module booting up or
updating firmware
Searching for IP address
Ready to pair and register
In accessory pairing mode –
searching for wireless on-demand
recirculation accessory (push
button, motion sensor, etc.)
Pairing successful to wireless on-
demand recirculation accessory
(push button, motion sensor, etc.)
Ready for/attempting cloud
registration
Cloud registration successful
Module connected to local Wi-Fi,
but cannot access Internet
Module is not able to connect to
local Wi-Fi
Initiating factory reset
Condition
