- Page 1 Star Manufacturing International Inc. Installation 10 Sunnen Drive Operating St. Louis, MO 63143 Instructions Phone: (314) 781-2777 2M-Y8967 Rev. C 01/06/05 FAX: (314) 781-3636 DEEP FAT FRYER MODEL 530F...
-
Page 2: Power Supply
POWER SUPPLY The Model 530F is wired at the factory for This fryer is equipped for the voltage and operation on a three phase power supply. wattage indicated on the nameplate mounted For specifi... - Page 3 CONTROLS NOTE: Baskets should be allowed to drain after A. ON/OFF TWO-POLE SWITCH frying cycle. The kettle handles serve as basket Located on the front panel is a two-pole hangers. switch which turns power on or off. An indicator light (Power On) is located on the IDLING control housing.
- Page 4 CAUTIONS FOR ALL DEEP FAT FRYERS NEVER LEAVE AN OPERATING FRYER UNATTENDED REMEMBER HOT OIL IS DANGEROUS - RESPECT IT! 8. If your fryer starts to smoke or boil 1. Hot oil is dangerous - Severe burns can abnormally, cut off the energy supply result when hot oil contacts the skin.
- Page 5 CARE OF FAT In three to six months you may spend as much for fat A number of commercial devices and materials are as you paid for your kettle. So fat is an item you want available to aid in eliminating fat impurities. There are to know all about;...
- Page 6 HANDY FRYING CHART TEMP TIME IN FOOD COATING PROCEDURE MINUTES POTATOES Standard French Fries Cut in uniform pieces 1/2” Blanch Only square the long way 3-1/2 Brown Only 3-1/2 Long Branch Cut in uniform pieces 3/4” square the long way 7-10 Julienne (shoe string) Cut in uniform pieces 1/8”...
- Page 7 LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
- Page 9 STAR MANUFACTURING INTERNATIONAL, INC. MODEL 530F 208/240V SK 1301 12/21/93 DR: BN...
-
Page 10: Parts List
PARTS LIST 01/06/05 EFFECTIVE 08/12/13 BBE 530F 30 Pound Deep Fat Fryer MODEL Number Part Number Number Description Unit E1-Y7820 COVER-ELEMENT HOUSING 2T-Y1668 THERMOSTAT, SAFETY 2A-Y7817 ROD, LOCKING - LT. 2A-Y7816 ROD, LOCKING - RT. E1-530056 LINK ASSEMBLY E1-Y7819 BRACKET...
