YOUR COOKER

Control panel

1 2 3 4 5 6
1. Control knob for cooking zone left front
2. Control knob for cooking zone left rear
3. Oven function knob
4. Temperature dial knob
5. Control knob for cooking zone right rear
6. Control knob for cooking zone right front

Ceramic hob description

7 8
9 10
7. Cooking zone left rear, 1.2 Kw / Ø 145 mm
8. Cooking zone right rear, 1.8 Kw / Ø 180 mm
9. Cooking (double) zone left front, 0.7/2.1 Kw / Ø 120/210 mm
10. Cooking zone right front, 1.2 Kw / Ø 145 mm
EN 5
