ALYA SERIES
SERIAL COMMUNICATION LOP
INSTALLATION MANUAL
TFT Display
Document Version: v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALYA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Aybey Elektronik ALYA Series

  • Page 1 ALYA SERIES SERIAL COMMUNICATION LOP INSTALLATION MANUAL TFT Display Document Version: v1.0...
  • Page 2 Figure 1 Figure 2 Figure 3 ALYA LOP Contents  ALYA Serial Communication LOP  Mounting Dowels and Screws  User Manual and Installation Manual  Terminating Resistor for systems without a shaft pit board with CAN interface.  SD Card 1- Mechanical Installation 1.1 Open the front cover by pressing the spring mechanism at the bottom center of the ALYA LOP with a screwdriver.
  • Page 3 2- Electrical Connections Terminating Resistor Figure 4 Figure 5 2.1 Connect the CANBUS cable terminals to the LOP interface in the control panel (100- 1000-CL1-CH1). 2.2 If your system includes a shaft pit control box with CAN interface as shown in Figure 4, then connect all LOPs with CANBUS cables with two white rectangular sockets.
  • Page 4 3- Operation and Adjustment Operations There are 3 programming buttons on the board: UP, DOWN and ENT. You can increase the value of a parameter by pressing UP and decrease it by pressing DOWN button. After setting it to the desired value, press ENT button shortly to confirm. In order to enter adjustment menu press 3 seconds ENT button.
  • Page 5 4- Firmware Update  The software of TFT display can be updated by using SD card. The procedure for updating the software is as follows:  Save the new file must into the SD card.  Switch off the power of LOP. ...
