Toshiba 32TL515U Owner's Manual

Integrated high definition lcd television, led tv.
Hide thumbs

Advertisement

Integrated High Definition
LCD Television
32TL515U
42TL515U
47TL515U
55TL515U
For an overview of steps for setting up your new TV, see page 12.
Note: To display a High Definition picture, the TV must be receiving a
High Definition signal (such as an over-the-air High Definition TV
broadcast, a High Definition digital cable program, or a High
Definition digital satellite program). For details, please contact your
TV antenna installer, cable provider, or satellite provider.
© 2011 TOSHIBA CORPORATION
All Rights Reserved
Owner's Record
The model number and serial number are on the back
and side of your TV. Record these numbers in the
spaces below. Refer to these numbers whenever you
communicate with your Toshiba dealer about this TV.
www.support.toshiba.com
Model number:
Serial number:
VX1A00206300
TD/M
