Cateye GVOLT 50 HL-EL550G RC Manual

RECHARGEABLE HEADLIGHT
HL-EL550G RC
Manual K 1190
Before using the light, please read this manual and
the included separate sheet "LITHIUM-ION / LITH-
IUM-ION POLYMER BATTERIES" thoroughly, and
keep them for future reference.
Design Pat. Pending
Copyright© 2016 CATEYE Co., Ltd.
3
HLEL550GRC-160614
Light unit
USB cable
(MICRO USB)
FlexTight™ bracket
(H-34N)
2 HOW TO MOUNT TO A BICYCLE
Bracket
Rubber pad Dial
1
Strap
PRECAUTIONS ON USE
ENG
• Before your trip, please make sure the light is fi rmly mount-
ed to the bracket, it lights up, and the light is not blocked by
baggage, etc.
• Do not place it within children's reach.
• Mounting the light unit too close to a wireless computer
may adversely affect the reading of the computer.
• In preparation for unexpected battery shutoff, we recom-
mend you carry a spare light.
• This product is water-resistant under normal daily use and
can be used in the rain. However, do not intentionally sub-
merge it in water.
1 HOW TO CHARGE
Charge jack cover
USB cable
2
1
To PC or USB battery charger
2
4
Screw
3 *1
1. Connect the light unit to your PC or
a commercial USB battery charger us-
ing the USB cable. (
The switch indicator turns on and
charging starts.
Indicator light
Standard charging time * When your PC is in sleep state, the
unit cannot be charged.
6 h
Approx.
1. Mount the bracket to the handlebar.
4
( –
1
2. Insert the light unit into the bracket
until it clicks, and adjust the beam
angle. (
3. To remove the light unit, pull out it
forward while pressing down on the
release button (
* To re-adjust the beam angle, loosen
the dial enough to move the bracket,
and fi rmly tighten it after adjustment.
* The light can be mounted under the
Release
button
5
handlebar.
• If the light unit or parts become dirty with mud, etc., clean
with a soft cloth which is moistened with mild soap. Never
apply paint thinner, benzine or alcohol; damage will result.
PRECAUTIONS ON DISPOSAL
When disposing of the light unit, remove the internal re-
chargeable battery and dispose of it according to local regu-
lations.
Before Initial Use
This unit is shipped with a small charge to check the light.
Be sure to charge it before use, according to the instructions
"HOW TO CHARGE".
* We recommend using 500+mAh
1 – 2 ).
* If the indicator fl ashes rapidly, there
State 2. After charging is completed, remove
the USB cable, and install the charge
On Charging
jack cover.
Off Charging is completed
* Charging and lighting times are ap-
proximate values, and will vary by
environmental and user conditions.
CAUTION!:
)
3
• Be sure to tighten the dial by hand.
)
4
• Check the dial and screw (*1) on the
).
5
• Round off the cut edge of the bracket
(USB 2.0) USB battery charger.
is a charging error. Remove the
cable and try again.
When you tighten it too hard with
a tool, the screw thread may be
stripped.
bracket periodically, and use them
without any loosening.
strap to prevent injury.
