T70 2 ATEX Transmitter

Charger and battery

CB70 and BT06K specifications

Setting up the CB70 battery charger

10 | © Danfoss | October 2020
CB70 battery charger
Specification
Standard AC power supply
Optional AC power supply
DC power supply
BT06K ATEX battery
Specification
Voltage
Capacity
Charging temperature
Discharge temperature
Charging mode
Weight
The battery is protected by an internal fuse.
Use the information below to properly set up the CB70 batter charger.
The battery charger has two charging compartments that can simultaneously charge two batteries.
1. Connect the charger to a power source using the cable supplied.
The red LED will switch.
Value
230 Vca ± 10%, 50
115 Vca, 60 Hz
From 10.5 V to 35V
Value
4.8 V
500 mAh NiMH
From 0° to 45° C
From -20° to 50° C
Fast (<2h) and intelligent
70.3 g
