Inserting the RealPort Integrated PC Card
Connecting to the LAN (RJ-45)
PC CARD TYPE III OR DUAL
TYPE II SLOT
LAN ACTIVITY (YELLOW)
RJ-45
Hardware Installation
LAN LINK
ORANGE - 100Mbps
GREEN - 10Mbps
1-3
