Dc Voltage Measurements - Extech Instruments EX430A User Manual

Operating Instructions
1. ALWAYS turn the function switch to the OFF position when the meter is not in use.
2. If "OL" appears in the display during a measurement, the value exceeds the range you have
NOTE: On some low AC and DC voltage ranges, with the test leads not connected to a device, the

DC VOLTAGE MEASUREMENTS

1. Set the function switch to the green V position.
2. Press the SELECT button to indicate "DC" on the display.
3. Insert the black test lead banana plug into the negative COM jack.
4. Touch the black test probe tip to the negative side of the circuit.
5. Read the voltage in the display.
Find Quality Products Online at:
WARNING: Risk of electrocution. High-voltage circuits, both AC and DC, are very dangerous and
should be measured with great care.
selected. Change to a higher range.
display may show a random, changing reading. This is normal and is caused by the high-input
sensitivity. The reading will stabilize and give a proper measurement when connected to a circuit.
CAUTION: Do not measure DC voltages if a motor on the circuit is being switched ON or OFF.
Large voltage surges may occur that can damage the meter.
Insert the red test lead banana plug into the positive V jack.
Touch the red test probe tip to the positive side of the circuit.
