Material Specification - Akh2.2 With Manual Gear - Flowserve AKH2.2 Technical Manual

Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200

Material specification - AKH2.2 with manual Gear

310
010
080
040
050
No.
400
410
420
430
440
445
450
455
Technical Manual
410
Designation Quantity
gear 1
handwheel 1
bracket 1
adapter 1
hexagon bolt 4
serrated lock washer 4
hexagon bolt 4
serrated lock washer 4
400
455
450
430
420
440
445
Material
steel (yellow chromated)
stainless steel
stainless steel
stainless steel
stainless steel
stainless steel
AKH2.2 - atomac ball valve - full port
Register:
Page:
Date:
Revision:
Material-No. DIN
1.0037 DIN EN 10025-2
1.4104 DIN EN 10088-3
1.4301 DIN EN 10088-3
1.4301 DIN EN 10088-3
1.4301 DIN EN 10088-3
1.4301 DIN EN 10088-3
12
11
04.1995
06.2020
ASTM / AISI
A 283 B
AISI 430 F
A 193 B8
AISI 304
A 193 B8
AISI 304
