Operating the FlexStep Compact from UPPER level

From the upper level, push and hold the button. The staircase starts by ele-
vating the ramp to an interlocked roll-off protection (fig. 7). The staircase moves down
turning into a lifting platform which is then elevated to the upper level (fig. 8). Move onto
the platform slowly, (in wheelchair: lock the wheel brakes), push and hold the joystick
DOWN and the lifting platform moves down to the lower level and lowers the ramp. Leave
the lifting platform carefully (fig. 9).
Fig. 8 Fig. 9
Fig. 7
Elevating the ramp Driving onto the lift Leaving the lift

Operating the FlexStep Compact from LOWER level

From the lower level, push and hold the button. The operation starts by
elevating the ramp (fig. 7). The staircase moves down turning into a lifting platform at the
lower level. The ramp lowers (fig. 10). Move onto the platform slowly, (in wheelchair: lock
the wheel brakes) (fig. 11), push and hold the joystick UP and the lift moves up after the
ramp is elevated to an interlocked roll-off protection. The lifting platform stops automati-
cally at the top level. Leave the lifting platform carefully (fig 12).
Fig. 11 Fig. 12
Fig. 10
Lowering the ramp Driving onto the lift Leaving the lift
4
