PRINTER'S INSTRUCTIONS:
MANUAL,QUICK START,NOVA,CO - NORTEK P/N: 10015712B- INK: BLACK PLUS PMS 286C - MATERIAL: 105G COATED PAPER - SIZE: 105MM X 105MM - SCALE:
1-1 - BINDING: TRIM, FOLD AND SADDLE STITCHED - PAGE 1 OF 32
ADT Carbon
Monoxide Alarm
Setup Guide

Advertisement

loading

Related Manuals for Samsung SmartThings ADT Carbon Monoxide Alarm

Summary of Contents for Samsung SmartThings ADT Carbon Monoxide Alarm

  • Page 1 PRINTER’S INSTRUCTIONS: MANUAL,QUICK START,NOVA,CO - NORTEK P/N: 10015712B- INK: BLACK PLUS PMS 286C - MATERIAL: 105G COATED PAPER - SIZE: 105MM X 105MM - SCALE: 1-1 - BINDING: TRIM, FOLD AND SADDLE STITCHED - PAGE 1 OF 32 ADT Carbon Monoxide Alarm Setup Guide...
  • Page 2 Setup Take the ADT Carbon Monoxide Alarm to where you intend to mount it after setup. • Make sure you are within 350 feet from the ADT Security Hub. (Exact range depends on your home’s construction, the environment, the position of the ADT Security Hub, and the position and number of other connected devices.) •...
  • Page 3 Setup 2. Use the SmartThings app on your smartphone to select the “My Home” tab. Select "Things", and then “Add a Thing". 3. Use the SmartThings app to scan the QR code on the front of the alarm and then follow the on-screen instructions to complete setup.
  • Page 4 Setup 4. Remove the tab on the carbon monoxide alarm Inst marked “Pull This Tab”. alar • Carbon Monoxide Alarm (Back) • • to m Battery Tab stan 5. Remove the QR code from the front of the alarm and attach it inside the ADT Security Hub User Guide for future reference.
  • Page 5 Placement Install the ADT Carbon Monoxide Alarm in a place where the alarm can be heard easily. Ideally, a carbon monoxide alarm should be installed in: • Every room containing a fuel burning appliance. • Within 10 feet of a sleeping area. •...
  • Page 6 Placement Carbon monoxide alarm suggested Locations: of t • Hallway Attic • • Bedroom Master Bedroom • Family Room Kitchen • • Basement Garage •...
  • Page 7 Placement Do not place the ADT Carbon Monoxide Alarm in any of the following areas: • In the immediate vicinity of a cooking appliance (keep it at least 5 feet away from it). • Outside the building. • In an enclosed space, e. g. in or below a cupboard. •...
  • Page 8 Placement • Over heat sources such as radiators or hot air vents. If lo • Where it would be obstructed, e.g. by curtains or furniture. • • In an area where the temperature could be below -50°F or above 104°F. •...
  • Page 9 Placement If locating the ADT Carbon Monoxide Alarm in a room with a fuel burning appliance: • If mounted on a wall, it should be located at a height greater than the height of any door or window but still be at least 5.9 inches from the ceiling. •...
  • Page 10 Placement • If there is a partition in the room, the alarm should be located on the same side of the partition as the potential source. If locating the ADT Carbon Monoxide Alarm in a bedroom or in rooms remote from a fuel burning appliance: •...
  • Page 11 Placement Carbon Monoxide Alarm Ceiling Placement: Not This Area 4 Inches (10cm) Anywhere In This Area 3 Feet 3 Feet (0.9m) (0.9m) Carbon Monoxide Alarms should face out in this position: Wall Behind Alarm Carbon Monoxide Alarm (Front)
  • Page 12 Mounting Install the mounting base using the two screws and anchors provided. Ceiling 12 inches 12 inches from wall from wall Mounting Base Carbon Monoxide Alarm (Front)
  • Page 13 Mounting Fit the alarm inside the base by aligning it over the base, then turn the alarm in a clockwise direction until it clicks into place. The three LEDs will flash while the alarm powers up. Test the alarm after completing the installation.
  • Page 14 Testing Test the ADT Carbon Monoxide Alarm weekly by pressing and holding the test button for a few seconds while the ADT Security Hub is in Walk Test Mode. See the ADT Security Hub User Guide for more details. Replace the alarm when the “Replace unit by” date has been reached (check label on the side of the device).
  • Page 15 Testing practitioner. Individuals with medical problems may consider using warning devices which provide audible and visual signals for carbon monoxide concentrations under 30 ppm.

  • Page 16: Troubleshooting

    Troubleshooting To r If th If the alarm does not sound when you press the test button: Make sure the batteries are properly inserted and then wait 15 seconds. Hold button down firmly for at least 5 seconds. Check the alarm is secured correctly on the mounting plate.
  • Page 17 To reset the alarm: Troubleshooting If the alarm did not pair successfully with the ADT Security Hub, follow these instructions to reset it: Press and release the test button twice. Press and hold the button until the red LED starts blinking quickly.
  • Page 18 Troubleshooting Reset Button ligh carb diff turn...
  • Page 19 When the ADT Carbon Monoxide Alarm detects potentially dangerous levels of carbon monoxide, it flashes the red light immediately and then sounds a loud alarm if the carbon monoxide persists. Alarm - Red LED Fault - Amber LED Power - Green LED The below table shows how the alarm reacts to different levels of carbon monoxide gas and exposure time.
  • Page 20 The rate of flashing of the red light indicates the level of carbon monoxide. If your alarm sounds, follow the instructions in the “What To Do” column. • Caution: The alarm only indicates the presence of carbon monoxide gas in the area where the ADT Carbon Monoxide Alarm is located.
  • Page 21 The following symptoms are related to CARBON MONOXIDE POISONING and are to be discussed with ALL members of the household: • Mild Exposure: Slight headache, nausea, vomiting, fatigue (often described as flu-like symptoms). xide • Medium Exposure: Severe throbbing headache, drowsiness, confusion, fast heart rate.
  • Page 22 Alarms What You Hear / See What It Means No beeping, red LED Low levels of carbon monoxide blinking once every 3 seconds. detected. Siren beeping, red LED Low levels of carbon monoxide blinking once every 3 seconds. detected for 60+ minutes. No beeping, red LED Moderate levels of carbon blinking twice every 3 seconds.
  • Page 23 What To Do Open a window or door to get fresh air. Open a window or door to get fresh air. Press the Hush button to mute the alarm. Open a window or door to get fresh air. Investigate the source of the carbon monoxide.
  • Page 24 Maintenance What You Hear / See What It Means No beeping. Normal operation. 1 Beep every minute. Low batteries. Amber LED flash once every 48 seconds, green LED off. 2 Beeps every minute. Carbon monoxide alarm Amber LED flash twice every error.
  • Page 25 What To Do No action. Replace batteries. Replace unit with same brand. Replace unit with same brand.
  • Page 26 Suggestions The ADT Carbon Monoxide Alarm monitors for carbon monoxide in your home. When carbon monoxide is detected, the alarm sounds and a notification is sent to your ADT Security Hub. Your ADT Security Hub can then send an alert to your smartphone, automate connected devices, or initiate optional ADT professional monitoring services (additional fees apply).
  • Page 27 Suggestions There are many ways you can use an ADT Carbon Monoxide Alarm in your home: • Put one in a room containing a fuel-burning appliance and set it to initiate optional ADT professional monitoring services when carbon monoxide is detected in your home (additional fees apply).
  • Page 28 Suggestions Note: To ensure proper functioning, all connected devices must be configured correctly. This alarm is not designed to be interconnected with other manufacturers' products unless otherwise specified. with Visit SmartThings.com/Welcome for more ideas, tips, and special offers.

  • Page 29: Works With Smartthings

    Works With SmartThings SmartThings works with a wide range of connected devices, including lights, cameras, locks, thermostats, and sensors. It also works with the Google Assistant and Amazon Alexa so you can control your smart home with voice commands. Look for the Works with SmartThings label next time you’re buying a connected device for your home, or visit SmartThings.com to see the full list of compatible devices.
  • Page 32 SmartThings, Inc., 665 Clyde Ave, Mountain View, CA 94043, USA. Information in this document is subject to change without notice. Copyright 2017 SmartThings, Inc. All rights reserved. ADT and the ADT logo are marks and/or registered marks of ADT. Unauthorized use is strictly prohibited.
